Precision Automation for Complex Inserts and Variable Formats.
When flexibility matters: Engineered for rapid changeovers (≤20 min), complex inserts, and emerging-market conditions.
1,000-2,000 cph
2,000-5,000 cph
Machine Class Comparison:
| Type | Throughput | Automation Level | Footprint | Key Benefit |
|---|---|---|---|---|
| Semi-Auto Linear | 1,000-2,000 cph | Operator loads product | Compact | Low-cost entry |
| Entry-Level Auto | 2,000-3,500 cph | Basic robotic insertion | Medium | Labor reduction |
| Advanced Auto | 3,000-5,000 cph | Integrated vision systems | Large | Pharma compliance |
| Hybrid Systems | 4,000-6,000 cph | Robotic + linear motion | Custom | Complex kit packaging |
Linear Cartoning Systems: Flexible Automation for Box Packaging.
Diesel-compatible operation • 50°C ambient tolerance • Arabic/French HMIs
Humidity-resistant components (80% RH) • Vietnamese/Thai interfaces • Compact design
LOCUS ROBOTICS delivers turnkey linear cartoning systems engineered for complete automation — eliminating manual handling from carton erection to final sealing. Seamlessly integrated downstream of filling, capping, and labeling lines.
Seamless Line Integration
Direct downstream integration with:
Tube filling machines
Vial labeling systems
Blister packaging lines
Optional add-ons: Tamper-evident labeling, thermal transfer printing, vision inspection
1,000-5,000 CPH Automatic Linear Cartoner — For Cosmetics & Pharm Plant.
Precision Engineering for Emerging Markets
1. Coding Systems:
— Thermal transfer printers (TTI)
— Laser markers (foil/plastic)
— Inkjet coders (CIJ/DOD)
2. Quality Assurance:
— Checkweighers (±0.1g accuracy)
— Vision inspection (missing inserts, seal integrity)
3. Traceability:
— Aggregation systems (bundle-case-pallet)
— Russia’s «Chestny ZNAK» compliance suite
4. Specialized Handling:
— Tube collators
— Sachet stackers
— Aerosol magnetic stabilizers
The Flexibility Advantage
Switch between carton formats in <20 minutes:
Cosmetics: Magnetic closure boxes, drawer-style sets
Pharma: Child-resistant (CR) packs, multi-lingual inserts
Veterinary: Syringe trays, temperature indicators
Material Flexibility:
Product Type Specialized Handling Industry Example
| Irregular Bottles | Multi-gripper robotic arms | Cosmetic serums (5-20ml) |
| Tubes | Roller-conveyor orientation | Toothpaste, veterinary ointments|
| Aerosols | Magnetic stabilization | Deodorants, automotive chemicals|
| Strip-Packs | Vibratory channel collation | Pharma monodose |
| Bundled Items | Robotic stacking end-effectors | Hookah tobacco sachets |
| Parameter | Standard Range | High-Speed Option | GMP Pharma Edition |
|---|---|---|---|
| Throughput | 500-3,000 cph | 6,000-8,000 cph | 2,000-4,000 cph |
| Carton Size | 30-300mm (L) | 20-400mm (L) | 25-200mm (L) |
| Material Compatibility | ECT 32-44 board | Corrugated up to 200gsm | FDA-approved inks |
| Changeover Time | < 20 min | < 45 min | < 30 min |
| Compliance | CE, UL | CE, UL | EU Annex 1, 21 CFR Part 11 |
Seamless upstream integration with:
Filling Lines: Liquid fillers, tube sealers
Labeling Systems: Wrap-around, front/back labelers
Inspection Modules: Vision, leak detection
Downstream expansion options:
Case Packers (case erectors, tray formers)
Palletizing Systems (robotic, layer)
Pallet Wrappers (stretch hood, shrink tunnel)
✅ 24-month performance guarantee | ✅ Local technicians in 18 countries
Free line configuration for your products, throughput validation testing!
Contact Packaging Specialists:
Compliance Roadmap:
CE, EAC, ISO 9001 certifications.
GMP-ready: 316L SS contact parts, CIP/SIP capabilities.
ATEX options for chemical solvents.
