LOCUS ROBOTICS manufactures ATEX/IECEx-certified dosing and filling systems for flammable liquids (LFLs), solvents, and explosive chemicals. Our semi-automatic and fully automatic machines ensure zero ignition risk in Zone 1/Zone 2 hazardous areas.
Explosion-Proof Liquid Dosing Systems for Flammable Chemicals, Solvents & Fuels – ATEX/IECEx Certified, Ideal for Oil & Gas, Petrochemical, and Pharmaceutical Industries.
✔ ATEX/IECEx/UL Compliance – Certified for alcohols, paints, fuels, and aerosols (Class I Div 1/Div 2).
✔ Explosion-Proof Design – All electronics (control panels, sensors, motors) are housed in remote pressurized enclosures (1–5m from filling zone).
✔ Material Options – 316L stainless steel, EPDM seals, and CIP/SIP compatibility for corrosive media.
Explosion-Proof Dosing Systems for Flammable Liquids – Zero Sparks, 100% Safety.
ATEX & IECEx Certified | Precision ±0.5% | Built for Chemicals, Fuels & Pharmaceuticals.
✔ ATEX Zone 1/Zone 2 compliant – Safe for ethanol, acetone, petroleum.
✔ 316L stainless steel w/ EPDM seals – Resists corrosion, FDA-compatible.
✔ No-drip nozzles – Zero waste with viscous fluids (up to 50,000 cP).
| Parameter | Specification |
|---|---|
| Accuracy | ±0.5% of set volume |
| Flow Rate | 10–500 mL/min (adjustable) |
| Explosion Rating | ATEX II 2G Ex db IIC T6 |
Pharma: Alcohol-based sanitizers, solvents.
Chemicals: Paints, adhesives, acetone, Solvents, paint thinners.
Oil & Gas: Diesel additives, lubricants, kerosene.
Cosmetics: Perfumes, alcohol-based sanitizers.
Food/Beverage: Vodka, whiskey, ethanol extracts.
Explosion-Proof Dosing Systems for Hazardous Liquids
Engineered for flammable and corrosive chemicals (ethanol, acids, fuels), our ATEX/IECEx-certified fillers feature stainless steel 316L construction, CIP/SIP compatibility, and ±0.5% dosing accuracy. Ideal for pharmaceutical solvents, oilfield additives, and industrial coatings. Includes 2-year warranty and 24/7 safety support.
Remote Control Panel – Intrinsically safe HMI with EX-rated buttons.
Hazardous-Area Sensors – ATEX-certified level/flow detectors.
Explosion-Proof Motors – Servo, stepper, or pneumatic drives.
| Model | Technology | Throughput | Accuracy |
|---|---|---|---|
| Auto-Piston Filler | Servo-driven piston | Up to 200 BPM | ±0.5% |
| Gravimetric Dosers | Weight-based filling | 50–500 mL/min | ±0.1g |
| Peristaltic Systems | Pneumatic tube pumps | 10–100 L/h | ±1% |
Optional: Custom aerosol filling lines for spray cans.
Turnkey Hazardous-Zone Solutions – From standalone dosers to full explosive-proof lines.
Global Certifications – ATEX, IECEx, UL, TR CU (EAC).
24/7 Support – Spare parts, validation docs (SIL, FMEA).
Act Today, start Your Project:
✉ Email:mail@locuspack.com
📞 Phone: +7 927 056-19-99
