(Synthesis & Sublimation Systems), tailored for pharmaceutical, chemical, and food industries
Pharmaceutical-grade freeze dryers for thermolabile products:
Temperature Range: -80°C to +40°C
Shelf Area: 0.5-20m²
Applications: Vaccines, antibodies, probiotics
Critical Features:
• CIP/SIP validation (FDA 21 CFR 211)
• Condenser capacity: 100kg ice/24h
• Residual moisture: ≤3%
Jacketed vessels for low-pressure reactions:
Pressure Range: 0.01 mbar to 5 bar
Materials: 316L SS, glass-lined, Hastelloy
Processes:
• Hydrogenation
• Distillation under vacuum
• Cryogenic crystallization
Industrial-scale solvent removal:
Sublimation Rates: 1-5 kg/m²/hr
Applications:
• Botanical extracts (food/pharma)
• Nanomaterial concentration
• Hazardous solvent recovery
| Parameter | Lab Scale | Pilot Scale | Production |
|---|---|---|---|
| Capacity | 0.5-5 L | 5-100 L | 100-5000 L |
| Temp Range | -80°C to +250°C | -70°C to +200°C | -50°C to +200°C |
| Vacuum Level | 0.001 mbar | 0.01 mbar | 0.1 mbar |
| Sterilization | Autoclave ports | SIP (steam-in-place) | Full CIP/SIP |
| Sector | Critical Processes | Compliance |
|---|---|---|
| Pharma | Lyophilized injectables, API synthesis | GMP, ICH Q7, Annex 1 |
| Biotech | mRNA vaccine stabilization | BSL-2 containment |
| Food | Freeze-dried probiotics, instant coffee | FDA 21 CFR 110, HACCP |
| Chemicals | High-purity metal organics, catalysts | ATEX, IECEx Zone 1 |
Energy Efficiency: 35% less power vs. rotary evaporators (multi-stage condensers)
Containment: OEL ≤1 µg/m³ for potent compounds (split-valve discharge)
Scale-Up Accuracy: Identical thermal profiles from R&D → production
Smart Control:
• PAT integration (mass spectrometry, NIR)
• Recipe management (21 CFR Part 11)
• Remote diagnostics via IIoT
| Requirement | Implementation |
|---|---|
| Sterility Assurance | VHP (Vaporized H₂O₂) chamber decontamination |
| Material Traceability | ASME BPE fittings, Ra ≤0.5 µm surface finish |
| Data Integrity | Electronic batch records with audit trails |
| Change Parts | Quick-release shelf assemblies (changeover <30 min) |
| Market | Standards | Validation Support |
|---|---|---|
| EU | EU GMP Annex 1, PED 2014/68/EU | EMA audit packages |
| USA | FDA 21 CFR 211, ASME BPE | IQ/OQ/PQ protocols |
| China | NMPA GMP, GB150 | CFDA application assistance |
| SE Asia | PIC/S GMP, ISO 13485 | Local agent commissioning |
Containment:
• Isolators for OEB 4-5 compounds
• Split valve powder discharge
Automation:
• Siemens PCS7/DeltaV control
• Automatic cake thickness detection
Safety:
• Redundant vacuum systems
• Emergency nitrogen purge
• Ex-proof motors (ATEX Cat. 1)
Engineered for mission-critical applications:
Vaccines: Controlled nucleation for uniform pore structure
High-Potency APIs: Containment to ≤1 µg/m³ OEL
Botanicals: Low-temperature terpene preservation
Scale Flexibility: Identical thermodynamics from 1L → 1000L
Request application engineering:
Lyophilization: Cycle optimization studies
Hazardous Synthesis: ATEX-certified reactors
Validation: GMP documentation packages
🌐 Request Compliance Audit: Free gap analysis with throughput simulation.
✅ GMP Compliance Guarantee
✅ 24/7 Multilingual Support
✅ 24-month performance guarantee
✅ Local technicians in 18 countries
Free line configuration for your products, throughput validation testing!
Contact Specialists for Packaging Equipment:
Compliance Roadmap:
