Side Transfer & Orientation Modules for Alignment&Labeling Bottom Vial
Bottom Labeling & Coding Solutions.
Locus-Robotics engineers precision side guide orienters that ensure perfect bottle positioning during conveyor transport. These critical components eliminate misalignment in high-speed bottling lines, reducing jams and product damage by 90%.
Side orienting modules secure vial/tare during horizontal conveyor gaps and transfer them to downstream sections. These systems enable precision bottom labeling (stickers/holograms) and inkjet marking (lot codes, expiry dates, serialization) on vial/tare bases.
Dual Synchronized Belts
Two laterally positioned belt conveyors with independent servo drives
Coordinated motion via centralized frequency inverter control
Gap Bridging
Installed between separated horizontal conveyors
Containers captured by orienting belts → transferred at preset speed
Speed Synchronization
Integrated encoder option for upstream/downstream timing alignment
Container Indexing
Upstream polyurethane foam indexing disc maintains container pitch
| Component | Function |
|---|---|
| Dual belt conveyors | Container gripping & transfer |
| Frequency inverter | Speed regulation (0-100% adjustable) |
| Rotary encoder | Positional synchronization |
| Foam-tipped indexing wheel | Gap control between containers |
Seamless Conveyor Pairing
- Compatible Systems:
- Belt conveyors
- Chain conveyors
- Modular plastic chains
- Mounting Options:
- Flush-mount for low-profile designs
- Overhead mounting for vertical adjustment
- Control Interfaces:
- Manual positioning
- Servo-automated adjustment (IoT-ready)
Engineered for Extreme Conditions
- SE Asia: Anti-fungal polymers (80% RH)
- Africa: Sand/dust seals (IP66)
- Middle East: UV-stabilized materials
- Eastern Europe: Cold-flex polymers (-35°C)
- LATAM: Corrosion-resistant coatings
Bottom labeling: Label applicator mounted under module
Inkjet marking: Printer positioned for bottom-surface coding
Compatible with:
Pressure-sensitive labelers
CIJ (Continuous Inkjet) printers
Laser markers
Standard: Polyurethane endless belts for cylindrical containers.
Specialized: Chain grippers for oval/elliptical containers.
Pharma/GMP: CIP-compatible stainless steel construction.
Bottling lines (beverage, chemicals, cosmetics).
Monoblocks (filling-capping-labeling systems).
Rinsing-filling-capping tri-blocks.
Automated labeling lines with bottom applicators.
| Parameter | Standard Range | Heavy-Duty Options |
|---|---|---|
| Guide Length | 0.5-5 m | Up to 15 m |
| Adjustment Range | 50-300 mm | 100-600 mm |
| Material | FDA-grade PP/PE | 316SS, UHMW-PE |
| Mounting | Tool-less clamps | Welded brackets |
| Angle Adjustment | ±10° | ±35° |
| Operating Temp | -30°C to +80°C | -50°C to +120°C |
| Compliance | CE, EHEDG | GMP, ATEX |
Active Alignment System
1. Spring-Loaded Guides: Auto-compensate for container variations
2. Wear Strips: Replaceable UHMW-PE friction surfaces
3. Diverging/Converging Zones: Gradual alignment without impact
4. Anti-Static Design: Prevents PET bottle adhesion
Key Features:
- Tool-less width adjustment in <60 seconds
- Impact-resistant composite construction
- Laser-engraved positioning scales
- CIP-compatible quick-release mechanism
Spring-loaded guides accommodate ±15% container size variations.
| Industry | Container Types | Special Features |
|---|---|---|
| Pharmaceuticals | Vials, syringes | GMP-compliant, Ra<0.8µm surfaces |
| Beverages | Glass/PET bottles | Drainage channels, mold resistance |
| Chemicals | Jerrycans, drums | Chemical-resistant 316SS guides |
| Cosmetics | Dropper bottles, jars | Scratch-free coatings |
| Metric | Locus-Robotics | Standard Guides |
|---|---|---|
| Jam Reduction | 90% | 55-70% |
| Changeover Time | 25 seconds | 2-5 minutes |
| Service Life | 50,000+ operating hours | 10,000-20,000 hours |
| Damage Rate | 0.3% | 2-5% |
Our K-10 series reduces line jams by 90% with tool-less changeover — critical for high-speed beverage lines switching between 10 bottle formats daily.
| Model | K-10 (Standard) | K-10C (Heavy-Duty) | K-10R (GMP) |
|---|---|---|---|
| Max Load | 30 kg/m | 80 kg/m | 50 kg/m |
| Guide Material | FDA-PP | UHMW-PE | 316L SS |
| Adjustment | Manual | Manual/Servo | Automated |
| Compliance | CE | CE, ATEX | GMP, FDA |
Lifetime Wear Strips: Free replacement program
3D-Printed Adapters: Custom interfaces for legacy systems
Global Emergency Service: 72-hour response guarantee
✓ Zero product spillage during transfer
✓ ±0.5mm labeling/marking accuracy
✓ Quick-change tooling for container format adjustments
✓ Compatible with vials, bottles, jars (50ml — 5L capacity)
Oval Container Handling • High Speed Synchronization.
Optimized Conveyor Integration for Reliable Bottling Lines.
Side Transfer/Orienting Modules
For Container Stabilization, Bottom Labeling & Marking Applications.
✅ GMP Compliance Guarantee
✅ 24/7 Multilingual Support
✅ 24-month performance guarantee
✅ Local technicians in 18 countries
Free line configuration for your products, throughput validation testing!
