LOCUS ROBOTICS manufactures compact peristaltic dosing systems for sterile, abrasive, and aggressive fluids – ideal for pharmaceuticals, cosmetics, and chemicals.
✔ Zero Cross-Contamination – Product only contacts disposable tubing
✔ Quick-Change Design – Swap tubes in under 30 seconds
✔ Material Options:
Standard: Santoprene® (1-10,000 cP)
Chemical-Resistant: PTFE-lined (acids/alkalis)
Pharma-Grade: Pharmed® BPT (USP Class VI)
Accuracy: ±1% (standard), ±0.5% (servo models)
Flow Rate: 10mL/min to 5L/min
Drip-Free: Spring-loaded pinch valves
| Model | Drive Type | Dosing Range | Best For |
|---|---|---|---|
| LFP-10D | Manual | 1-100mL | Labs, R&D |
| LFP-10T | Pneumatic | 50-500mL | Industrial chemicals |
| LFP-10S | Servo | 100mL-5L | Pharma, cosmetics |
Aseptic filling of vaccines
Cytotoxic drug handling (closed-system)
Flavor extracts, edible oils
USDA-compliant tubing options
Abrasive slurries (up to 30% solids)
EX-proof versions for flammables
| Parameter | Peristaltic | Piston Filler |
|---|---|---|
| Cleaning Time | 2 mins | 15 mins |
| Shear Sensitivity | Gentle | Moderate |
| Corrosion Risk | None | Possible |
Base Unit: Benchtop or floor-standing
Tubing Kits: Pre-sterilized, gamma-irradiated
Accessories:
Bottle holders
Foot pedal control
Optional:
Load cells for gravimetric verification
RFID-tagged tubing for traceability
Select Tubing Material: Based on chemical compatibility
Choose Drive Type: Manual/pneumatic/servo
