Automated CIP conveyor cleaning systems
Continuous Belt Cleaning for Sticky & Aggressive Products.
Sanitation Solutions for Pharma, Food & Cosmetic Production Lines.
Automated filling lines (linear fillers, monoblocks) require continuous conveyor sanitation when handling:
Adhesive products (jams, tomato paste, toppings).
Aggressive chemicals (cleaners, automotive fluids, industrial compounds)
Traditional cleaning causes costly downtime — our solution cleans during operation.
Industrial-grade cleaning modules for complete belt sanitization without disassembly. Eliminates product residue, microbial contamination, and cross-batch carryover in compliance with:
FDA 21 CFR Part 117 (Food Safety).
EU Annex 1 / GMP Guidelines (Pharma).
ISO 22000 Sanitation Protocols.
| Step | Mechanism |
|---|---|
| 1. Immersion | Conveyor chain dips into cleaning bath via lower sprocket |
| 2. Contaminant Removal | Submerged section scrubbed in detergent solution |
| 3. Continuous Operation | Self-tensioning system maintains contact during production |
| 4. Solution Management | Optional filtration/pH control for extended use |
Belt Compatibility: Plastic modular / Stainless steel chains
Tank Capacity: 15-200L (customizable)
Materials: 304/316L SS, POM acetal gears
Drive: IP69K-rated motor with torque limiter
Add-ons:
Ultrasonic cleaning modules
Automatic detergent dosing
Scraper blades for heavy residues
| Parameter | Standard | GMP Option |
|---|---|---|
| Construction | AISI 304 Stainless Steel | AISI 316L Electropolished |
| Pressure Rating | 15-40 bar | 20-60 bar |
| Nozzle Type | Rotary jet spray heads | Sanitary tri-clamp fittings |
| Flow Rate | 20-50 L/min | 30-80 L/min |
| Control System | IP65 NEMA-4 panel | PLC with SCADA integration |
Zero downtime sanitization technologies.
Chemical Producers:
Household cleaners ● Automotive fluids ● Construction chemicals
Food Manufacturers:
Tomato paste ● Sauces ● Jams ● Fruit pulps ● Hot beverages
High-Value ROI: Eliminates 30-90 min/hourly manual cleaning cycles
Pharma: Vial/bottle lines, lyophilizer loading
Food: Meat processing, sauce filling, dairy
Cosmetics: Cream fillers, tube sealers
Chemicals: Drum filling, IBC stations
Automatic Activation
Triggered by photoelectric sensors at line shutdown
360° Cleaning
Upper/lower belt surfaces + side guides
Chemical Sequencing
Caustic wash → Acid neutralization → Rinse → Sanitizer
Drain Recovery
Sloped collection trays with sanitary drain ports
✓ Zero line stoppage for cleaning
✓ 85% residue reduction vs. dry conveyors
✓ Explosion-proof (ATEX Zone 1 & Zone 2) versions
✓ Validatable for GMP/ISO 22000 compliance
✓ 55% faster cleaning vs. manual methods
✓ Tool-free nozzle adjustment for belt width changes
| Positioning | Use Case |
|---|---|
| Pre-filler | Prevents product contamination |
| Post-filler | Cleans spillage before capping |
| Monoblock integration | Built into filling-capping lines |
Inline Installation: Between filler & capper stations
Mobile Units: Rolling carts for multi-line use
Add-ons:
TOC (Total Organic Carbon) sensors
Dry-air blow-off modules
Wastewater pH neutralization
✅ GMP Compliance Guarantee
✅ 24/7 Multilingual Support
✅ 24-month performance guarantee
✅ Local technicians in 18 countries
Free line configuration for your products, throughput validation testing!
