Ergonomic Solutions for Labs, Startups, and Small-Batch Operations.
| Drive Type | Operation | Torque Range | Max Throughput | Best For |
|---|---|---|---|---|
| Mechanical | Hand-cranked | 1-8 Nm | 300 CPH | Budget operations |
| Pneumatic | Foot pedal control | 0.5-15 Nm | 500 CPH | Chemical labs |
| Electric | Push-button | 0.2-10 Nm (±3%) | 600 CPH | Pharma/GMP environments |
Note: For >600 CPH or automated integration, consider semi-automatic models
| Sealing Process | Cap Types | Tooling Examples |
|---|---|---|
| Crimping | Smooth aluminum, perfume caps | Flip-off seal jaws (K-series) |
| Torque Application | PET screw caps, Twist-Off™ | Adjustable chuck heads |
| Thread Rolling | Aluminum ROPP caps | 28/32mm threading rollers |
| Press-Fit Insertion | Rubber stoppers, plastic plugs | Compression anvils |
| Specialized | Guala™ closures, pump dispensers | Custom mandrels |
| Equipment Type | Sealing Method | Cap Compatibility | Throughput |
|---|---|---|---|
| Torque Controllers | Adjustable screwing | Screw caps (15-120mm) | 100-300 BPH |
| Press-Fit Stations | Vertical compression | Stopper inserts, snap caps | 80-200 BPH |
| Crimping Tools | Lever-arm crimping | Flip-off seals (K1-K3) | 50-150 BPH |
| ROPP Rollers | Hand-operated threading | Aluminum ROPP caps | 70-180 BPH |
Technical Highlights:
Torque range: 0.5-10 Nm (digital display models)
Material contact: 316L SS or FDA-grade plastics
Calibration: Traceable certification available
| Sector | Typical Use | Specialized Tooling |
|---|---|---|
| Pharma R&D | Vial stoppering | Lyophilization compatible |
| Cosmetics Lab | Dropper assembly | Gloss-protective jaws |
| Food Startups | Jar sealing | USDA-compliant materials |
| Chemical Pilot | Drum bung insertion | Solvent-resistant coating |
| E-Liquid Craft | CRC nozzle fitting | Child-lock verification |
Adjustable Height: 70-120cm working plane
Reaction-Free Operation: Dual-stabilization arms
Quick-Change Jaws:
Pharma: 13-33mm vial grippers
Industrial: 38-120mm drum adapters
Safety:
Splash guards (chemical models)
Finger-protection zones
| Feature | Locus Manual | Standard Bench Tools |
|---|---|---|
| Torque Accuracy | ±5% | ±15-20% |
| Format Change | 90 seconds | 15+ minutes |
| GMP Documentation | Included | Not available |
| Seal Integrity | 99.2% | 85-90% |
Workflow Efficiency:
Operator output: 250-500 units/hour
Changeover time: <5 minutes
Floor space: 0.8m² per station
| Sector | Typical Caps | Recommended Model |
|---|---|---|
| Pharma Compounding | 13-20mm vial stoppers | Electric with digital torque |
| Cosmetics Startups | 18-40mm pump dispensers | Pneumatic press |
| Craft Beverages | 26mm crown seals | Manual crimper |
| Chemical Samples | 45-63mm drum bungs | Lever-action inserter |
| E-Liquid Boutiques | CRC nozzles | Twist-lock installer |
Included Accessories:
Cap gripper set (5 sizes)
Calibration certificate
Gasket maintenance kit
Operation videos (QR-linked)
Lab Scale-Up:
Manual crimping → Semi-auto capping upgrade path
Field Service:
Portable kits for contract manufacturers
Training Cells:
GMP practice stations for new technicians
Our CM-50 manual capper seals vaccine vials with 0.8-1.2 Nm precision — ideal for clinical trial material handling in mobile labs.
| Scenario | Recommended Solution |
|---|---|
| Prototyping <100 units/day | Benchtop torque controller |
| Sterile compounding | Press-fit isolator station |
| Hazardous chemicals | ATEX-compliant roller |
| Artisanal products | Luxury cosmetic crimper |
+ Patented torque amplification (10:1 leverage)
+ Interchangeable tooling system
+ Digital models with batch logging
- Not for >550 BPH production
+ Custom tooling for niche caps (Guala™, Twist-Off™)
+ Pharma-grade calibration (±0.1 Nm)
+ 65% cost savings vs automated systems
- Limited to low-volume production
Included With Every Unit:
Cap-specific tooling jaws
Torque calibration certificate
Ergonomic workstation mount
GMP documentation (electric models)
When Scaling Production:
500-1,500 CPH: Semi-automatic cappers
1,500+ CPH: Linear automatic systems
Complex Caps: Robotic sealing cells
Our CM-50 electric capper delivers GMP-compliant sealing for clinical trial vials:
Precision Control: 0.8-1.2 Nm torque range
Quick-Change: Switch between 13-33mm vials in 90 seconds
Data Logging: USB export for audit trails
Space Efficient: 60cm bench footprint
Precision Terminology Notes:
«BPH» (Bottles Per Hour)
«ROPP» maintained
«CRC» for Child-Resistant Closures
«GMP» not «GxP» for manual tools
«Jaws» not «grippers»
Need sealing solutions for prototypes or limited runs?
Need sealing solutions for R&D or pilot production?
✉️ Email: mail@locuspack.com
📞 Phone: +7 927 056-19-99
Request our ‘Starter Kit Catalog’ with 50+ pre-configured solutions!Ask about:
Lease-to-own options.
Same-day shipping for in-stock models.
Custom jaw fabrication.
