LOCUS ROBOTICS specializes in vacuum-assisted filling technology for luxury perfumes, eau de toilette, and alcohol-based cosmetics. We delivers specialized vacuum dosing systems for alcohol- and oil-based perfumes, ensuring perfect fill levels (±0.1mm accuracy) across all bottle designs.
✔ Level-Fill Precision – Optical sensors + overflow suction guarantee consistent meniscus lines
✔ Zero Waste – Recaptured excess fragrance returns to the dosing cylinder
✔ Speed: Up to 2,000 BPH (4-nozzle systems)
| Model | Nozzles | Accuracy | Bottle Capacity | Output |
|---|---|---|---|---|
| LVP-200R | 1 | ±0.1mm | 10-200mL | 500 BPH |
| LVP-200M | 4 | ±0.05mm | 50-500mL | 2,000 BPH |
| LVP-200V | 6 | ±0.03mm | 1-100mL | 3,500 BPH |
Silent Operation – <55dB for boutique environments
Material Options:
Standard: 316L electropolished SS
EX-Proof: ATEX-certified for alcohol-based perfumes
| Parameter | LOCUS Level-Fill | Standard Volumetric |
|---|---|---|
| Visual Consistency | Identical fill lines | Variable meniscus heights |
| Bottle Tolerance | Compensates for ±15% volume variance | Requires identical bottles |
| Fragrance Loss | <0.3% | 3-5% |
✔ Zero Oxidation – Closed-system filling preserves fragrance notes
✔ Anti-Spill Design – 45° angled nozzles for narrow-neck bottles
✔ Speed: 30-120 BPM (adjustable for crystal/fluted glass)
| Model | Nozzles | Accuracy | Best For |
|---|---|---|---|
| LVP-200L | 1-2 | ±0.1mL | Niche perfumers (100-500mL) |
| LVP-200G | 4-6 | ±0.05mL | Mid-volume (50-200mL) |
| LVP-200P | 8-12 | ±0.03mL | Luxury brands (10-100mL) |
Contact Parts: 316L SS with electropolished finish
Seals: PTFE/Viton® for alcohol resistance
Optional: 18K gold-plated nozzles for prestige lines
✅ Dual-Stage Vacuum – Removes air before/after filling
✅ Tare Memory – Auto-compensates for bottle weight variations
✅ CIP System – Solvent-resistant cleaning for fragrance changes
Perfume Oils: Alcohol-free attars
Spray Products: Eau de parfum with actuator valves
Travel Sizes: 1-10mL sample vials
| Parameter | LOCUS VPF | Gravity Filler |
|---|---|---|
| Evaporation Loss | <0.5% | 3-5% |
| Bottle Types | 50+ designs | <10 designs |
| Filling Angle | 45°-90° | Vertical only |
Filling Module:
Vacuum-assisted level control
Anti-drip nozzles for narrow necks
Capping:
Pneumatic crimpers for aluminum caps
Sprayer actuator installers
Finishing:
RFID-enabled labelers
Velvet-lined boxing systems
Optional:
Nitrogen blanketing for oxygen-sensitive oils
AI vision for fill-level QC
✅ «Thread-Perfect» Fills – Uniform presentation across batches
✅ 100% Fragrance Recovery – Patented overflow recycling
✅ Heritage Compliance – Meets Grasse craftsmanship standards
✅ 1:1 Fragrance Integrity – No top-note degradation
✅ Luxury-Ready – Mirrored finish, silent operation (<60dB)
✅ Global Compliance – IFRA, ISO 22716, FDA 21 CFR
Share Bottle Specs:
Neck diameter/tolerance
Alcohol content (%)
Bottle dimensions/neck type
Daily output targets
