Engineered for High-Speed Container Positioning in Harsh Environments.
Precision Closure Handling for Mid-Sized Production Lines.
While less common in some markets, disc cap orienters offer distinct advantages for automated capping operations. Locus-Robotics’ centrifugal systems deliver reliable, low-noise performance ideal for small-to-medium enterprises.
Industrial Disc Orientation Systems
Precision Alignment for Round Containers at 8,000+ Units/Hour
Locus-Robotics' disc orienters automate bottle positioning at line entry points, eliminating manual loading. Operators dump bulk containers into the hopper every 1-3 hours - reducing labor costs by up to 45%.
Key Industries Served:
- Pharmaceuticals (vials, ampoules)
- Chemicals (jerricans, drums)
- Cosmetics (dropper bottles, airless packs)
- Food (jars, bottles)
Technology Variants
1. Rotary Cone Disc Orienters
For standard round containers
- Operation Sequence:
1. Containers enter rotating conical disc with orientation slots
2. Correctly positioned bottles transfer to linear conveyor
3. Compressed air jets reject misoriented items (±0.5° accuracy)
- Best For: 15-150mm diameter containers
2. Central Spindle Orienters
For irregular/non-round geometries
- Operation Sequence:
1. Alignment spindle hooks container necks
2. Lifts and rotates mispositioned units
3. Side rollers finalize orientation
- Best For: Oval cosmetics packaging, square chemical containers
| Parameter | CF-30B | CF-30N |
|---|---|---|
| Throughput | 5,000 U/h | 4,000 U/h |
| Container Size | Ø15-150mm | 50-500mm H |
| Orientation Accuracy | ±0.5° | ±1.0° |
| Changeover Time | <10 min | <15 min |
| Air Consumption | 50 l/min | 30 l/min |
| Power | 1.8 kW | 2.2 kW |
Feeding: Caps enter inclined rotating disc with precision grooves.
Orientation: Correctly positioned caps engage with grooves.
Transfer: Aligned caps advance to exit track (escapement).
Rejection: Misoriented caps diverted via air-knife or mechanical gate.
Centrifugal force + groove geometry ensures positive orientation
Optimal Application Scope
✅ Best For:
- Medium-speed lines (1,000-4,000 caps/hour)
- Facilities with space constraints
- Noise-sensitive environments
⚠️ Limitations:
- Throughput ceiling vs. high-speed vibratory systems
- Requires feed elevator for continuous operation
- Limited to symmetrical closures
✅ Anti-Jam Technology: Patented air-knife rejection system
✅ Tool-Free Changeover: Magnetic quick-release tooling
✅ Global Compliance: CE, GMP, ISO 9001 certifications
✅ Extreme Environment Ready:
- Voltage: 220V-380V ±25%
- Temperature: -25°C to +50°C
- Protection: IP65 (dust/humidity)
Integration Features:
- Plug-and-play with Monoblocks or Filler Line
- OPC-UA/EtherNetIP communication
- <3hr installation time
| Benefit | vs. Vibratory Feeders | vs. Elevator Systems |
|---|---|---|
| Noise Level | 65 dB (35% quieter) | Comparable |
| Footprint | 0.8m² (45% smaller) | 65% smaller |
| Changeover | Tool-free <3 min | 3x faster |
| Maintenance | No wear parts | Simplified mechanics |
Key Strengths:
Minimal vibration transmission
Energy efficient (0.5 kW avg.)
Gentle handling of delicate closures
No magnetic interference (pharma-safe)
Pharmaceutical Lines
— Handles vaccine vials with <0.3mm positioning tolerance
— Cleanroom-validated models available
Chemical Packaging
— 316SS construction for corrosive environments
— Explosion-proof options (ATEX Zone 2)
Cosmetic Filling
— Scratch-free PU
-coated contact surfaces
— Gentle handling of PET/glass
| Industry | Typical Closures | Performance Gain |
|---|---|---|
| Craft Beverages | Crown caps, 38mm screw caps | 45% energy savings |
| Cosmetics | Dropper inserts, flip-top caps | Zero part damage |
| Pharmaceuticals | Serum stoppers, lyo closures | GMP-compliant operation |
| Chemicals | Child-safe caps, tamper-evident bands | Corrosion-resistant models |
Our CF-30F series delivers 92,4% orientation accuracy at 65 dB — the quietest cap handling solution for urban facilities.
Regional Advantages:
SE Asia: Compact footprint for crowded factories
Africa: Low power consumption (220V ±25%)
Eastern Europe: -25°C cold-start capability
LATAM: Minimal maintenance training required
Engineered for Your Market
- SE Asia: Tropicalized seals (80% RH operation)
- Africa: Sand filtration for pneumatic systems
- Eastern Europe: Anti-condensation heaters
- LATAM: Spanish/Portuguese HMI interfaces
| Model | CF-30 | CF-30V |
|---|---|---|
| Capacity | 1,200 caps/h | 3,600 caps/h |
| Cap Size | 15-60 mm Ø | 25-100 mm Ø |
| Power | 0.4 kW | 0.8 kW |
| Air Pressure | 0.6 MPa | 0.6 MPa |
| Noise | 62 dB | 68 dB |
Ready to Automate cap or corks Handling?
Closure Evaluation: Send samples for free compatibility test!
Noise Comparison Tool: See dB reduction vs. your current system!
✅ GMP Compliance Guarantee
✅ 24/7 Multilingual Support
✅ 24-month performance guarantee
✅ Local technicians in 18 countries
Free line configuration for your products, throughput validation testing!
