When floor space costs $150+/m²: Automated cartoning solutions occupying 65% less area than linear systems, delivering up to 2,500 cph throughput.
Diesel-compatible • 50°C ambient • French/Arabic HMI
80% RH tolerance • Vietnamese/Thai UI • Compact footprint
LOCUS ROBOTICS delivers turnkey rotary cartoning systems where every square meter counts. Engineered for cosmetics and pharma producers in space-constrained facilities across Vietnam, Nigeria, and Eastern Europe.
Machine Configuration Comparison:
| Model Type | Automation Level | Throughput | Footprint | Operator Role |
|---|---|---|---|---|
| Semi-Automatic | Basic | 500-1,500 cph | <4m² | Loads products & leaflets |
| Fully Automatic | Advanced | 1,500-2,000 cph | <6m² | Monitors operation only |
| GMP Pharma Edition | Validated | 1,000-1,800 cph | <5m² | Supervised operation |
Full operation cycle: box erection, vial loading, leaflet insertion, sealing. 220V-380V/50Hz configuration.
Precision Packaging Sequence
Technical Operation Sequence
1. Carton Erection: Vacuum-assisted box forming on rotary index table
2. Product Loading: Automatic insertion of bottles/tubes/lipsticks
3. Leaflet Placement: Collated document insertion
4. Sealing:
— Hot-melt adhesive (cosmetics/food)
— Pressure-sensitive tape (pharma)
— Security stickers (luxury goods)
5. Coding & Verification: Lot/expiry printing + vision inspection
The Space-Saving Revolution
Occupy 65% less floor space than linear systems:
Vietnam: Fits 10m² micro-factories in Ho Chi Minh City
Nigeria: Ideal for converted warehouse facilities
Poland: CE-certified for compact EU production sites
Industry-Specific Applications
| Challenge | Our Solution | Regional Benefit |
| Voltage Fluctuations | 100-500V stabilizers | Nigerian grid reliability |
| High Humidity | Corrosion-resistant SS316L | Vietnam monsoon season operation |
| Dust Contamination | IP54-rated electrical panels | Middle Eastern desert conditions |
| Language Barriers | Multi-language HMI interfaces | Polish/Spanish operator training |
| Parameter | Semi-Auto | Full-Auto | Pharma Edition |
|---|---|---|---|
| Speed | 500-1,500 cph | 1,500-2,000 cph | 1,000-1,800 cph |
| Carton Size | 50-200mm (L) | 40-250mm (L) | 30-180mm (L) |
| Changeover Time | < 15 min | < 20 min | < 25 min |
| Power Consumption | 3.5 kW | 5.2 kW | 4.8 kW |
| Compliance | CE, UL | CE, UL | EU Annex 1, GMP |
| Model | Automation Level | Operator Role | Throughput | Footprint |
|---|---|---|---|---|
| Semi-Auto | Basic | Loads products & leaflets | 500-1,500 cph | <4m² |
| Full-Auto | Advanced | Monitors operation | 1,500-2,000 cph | <6m² |
| Pharma Edition | Validated | Supervised operation | 1,000-1,800 cph | <5m² |
| Region | Technical Adaptation | Benefit |
|---|---|---|
| SE Asia | 85% RH resistant components | Ho Chi Minh City monsoon operation |
| Africa | 110-220-380-480V voltage stabilizers | Lagos grid fluctuation protection |
| Latin America | Spanish/Portuguese HMI | São Paulo operator efficiency |
| Eastern Europe | CE-compliant safety systems | Warsaw factory compliance |
— Coding Systems:
• Thermal transfer printers (TTI)
• Laser markers
• Inkjet coders (CIJ/DOD)
— Quality Assurance:
• Checkweighers (±0.0,5g)
• Vision inspection (missing inserts)
— Traceability:
• Russia’s «Chestny ZNAK» compliance
• GS1 barcode aggregation
— Downstream Integration:
• Case packers
• Palletizing systems
✅ 24-month performance guarantee | ✅ Local technicians in 18 countries
Free line configuration for your products, throughput validation testing!
Contact Packaging Specialists:
Compliance Roadmap:
CE, EAC, ISO 9001 certifications.
GMP-ready: 316L SS contact parts, CIP/SIP capabilities.
ATEX options for chemical solvents.
