Semi-Automatic Tablet Presses: Precision Compression for R&D and Small Batches
LTP-30 Pro semi auto tablet press with touchscreen GMP pilot scale.
Quick change punch die system for multi formula R&D.
LOCUS PHARM delivers GMP-ready manual & semi-automatic tablet presses bridging laboratory research and pilot-scale production. Ideal for:
Formula development & clinical trial batches
Low-volume nutraceuticals, supplevtyns & sport nutrinion
Corrosive chemical tablet prototyping
Core Advantages Over Competitors:
✅ Pharma-Grade Precision: ≤0.3% weight variation with servo-controlled force (5-50 kN)
✅ Tooling Flexibility: Swap punches/dies in <5 mins for multi-formula trials
✅ Compliance Ready: Optional IQ/OQ validation packages for 21 CFR Part 11
Technical Highlights:
Single-Punch Systems: 200-2,000 tablets/hour output
Material Options: 316L SS or Hastelloy® construction
Data Export: CSV/PDF reports for batch documentation
| Model | Compression Force | Max Output | Key Features | Target Use |
|---|---|---|---|---|
| LTP-10 | 50 kN | 1,500 tab/hr | Touchscreen HMI, auto-ejection | Pharma R&D |
| LTP-20 | 40 kN | 800 tab/hr | Acid-resistant seals, IP54 rating | Detergent/chemical R&D |
| LTP-30 | 60 kN | 2,000 tab/hr | Pre-compression, de-dusting | Pilot production |
Tooling Specifications:
Tool sets crafted from AISI 420C steel (HRC 58-62) with ≤10µm tolerance. Standard configurations include:
Round tablets: 3mm to 20mm
Custom shapes: Capsule, heart, scored
Engraving depth: Up to 0.8mm
Compliance Features:
Optional air purge for containment (OEB 3-4 compounds).
Audit trail with electronic signature capability.
From Lab to Market Faster!
✅ GMP Compliance Guarantee
✅ 24/7 Multilingual Support
✅ 24-month performance guarantee
✅ Local technicians in 18 countries
Free line configuration for your products, throughput validation testing!
Contact Specialists for GMP:
Compliance Roadmap:
CE, EAC, ISO 9001 certifications.
GMP-ready: 316L SS contact parts, CIP/SIP capabilities.
