LOCUS ROBOTICS engineers high-accuracy flow meter-based fillers for chemicals, food, and cosmetics — delivering ±0.2% dosing accuracy without mechanical contact.
| Type | Principle | Best For | Accuracy |
|---|---|---|---|
| Electromagnetic | Voltage pulses ∝ flow volume | Conductive liquids (σ >5μS/cm) | ±0.5% |
| Coriolis Mass | Phase shift in vibrating U-tubes | High-value/viscous liquids | ±0.1% |
| Vortex | Frequency of downstream vortices | Solvents • Oils | ±0.75% |
| Ultrasonic | Transit time difference of sound waves | Ultra-pure water • CIP fluids | ±0.3% |
Standard Models:
2-16 Nozzles (expandable to 24 with dual-row)
Fill Range: 10ml-30L (customizable)
Materials: 316L SS • PTFE • Hastelloy® • PEEK
Optional Upgrades:
✔ Pumping Systems:
Diaphragm (foaming products)
Centrifugal (low-viscosity)
Peristaltic (shear-sensitive)
✔ ATEX/EX Certification for flammable liquids
✔ 3-A Sanitary for food/pharma
Flow Meter Precision Filling Systems
Volumetric Accuracy Meets Industrial Reliability
- ±0.2% Dosing Accuracy - Coriolis/Mass Flow technology
- 50-500 Containers/Min - From 10ml vials to 20L jerrycans
- Zero Cross-Contamination - Sanitary tri-clamp connections
| Parameter | Flow Meter Fillers | Gravity Fillers | Piston Fillers |
|---|---|---|---|
| Accuracy | ±0.2% | ±1% | ±0.5% |
| Viscosity Range | 1-1,000 cP | 1-500 cP | Up to 1M cP |
| Changeover | <2 min | <5 min | <10 min |
| Best For | Solvents • Oils | Water • Juices | Pastes • Creams |
Pharma & Chemicals
- Active pharmaceutical ingredients (APIs)
- Aggressive solvents (316L/Halar® wetted parts)
Food & Beverage
- Edible oils • Flavors • Alcohol
- 3-A sanitary standards
Industrial
- Lubricants • Motor oils • Paint thinners
- ATEX options for flammable liquids
✔ Multi-Flowmeter Configs - 4-24 dosing channels
✔ Temperature Compensation - Automatic viscosity adjustment
✔ Batch Logging** - 21 CFR Part 11 compliant
✔ Leak-Free Quick Disconnects - Zero drip tooling
✅ Pharma: FDA 21 CFR • EMA GMP
✅ Food: 3-A • EHEDG
✅ Industrial: ATEX • PED
✅ Data: 21 CFR Part 11 • Batch genealogy
Chemicals
- Motor oils • Detergents • Paint thinners
- 0.5-5% cost savings via reduced giveaway
Food & Cosmetics
- Edible oils • Flavor extracts • Serums
- CIP-ready designs
Pharma (Coriolis Only)
- Solvent dosing for API production
- GMP-compliant batch logging
! vs Piston Fillers
+ 50% faster for thin liquids
+ No seal wear • Lower maintenance
! vs Peristaltic Pumps
+ Handles foaming products
+ 3x longer service life
! vs Gravimetric
+ 5x faster • Smaller footprint
! vs Positive Displacement Pumps
+ 50% faster for thin liquids
+ No moving parts in product stream
! vs Gravimetric Fillers
+ 5x better accuracy
+ Smaller footprint
Precision Package
✅ Free Liquid Test - Validate with your product
✅ Validation Support (Full GMP Documentation) - IQ/OQ/PQ protocols included
✅ 3-Year Sensor Warranty
✅ Material Certs - 3.1/3.2 for wetted parts
✅ Data Integrity - Audit trails • Electronic signatures
«Reduced solvent waste by 32.5% versus gravimetric filling — ROI in 9 months.»
— Chemical Producer, Poland«Achieved 98.92% fill accuracy for $2,000/L oncology drugs — reduced giveaway by $1.2M/year.»
— Top-10 Pharma Italy
