Description

Integrated Solution for Complex Pharmaceutical Manufacturing

The V-1000 system represents a significant leap in process efficiency for pharmaceutical production. By integrating three reactors with a central emulsifier, it eliminates intermediate transfers, reduces contamination risks, and streamlines complex synthesis workflows. This is ideal for processes requiring separate stages for reactions, ingredient mixing, and final high-shear emulsification or homogenization .

Key Technical Specifications & Operational Advantages

• Multi-Reactor Design: The system comprises three reactors, likely with a total system volume around 1000L. This allows for parallel or sequential processing—for example, using one reactor for an initial chemical synthesis, a second for preparing an aqueous phase, and a third for final emulsification and mixing .

• Advanced Emulsification and Homogenization: At the heart of the system is a high-shear emulsifier or homogenizer, capable of achieving speeds of 0-2880 RPM or higher to create stable, fine emulsions and dispersions essential for pharmaceutical formulations .

• GMP Compliant Design: Constructed from high-purity materials suitable for pharmaceutical applications, such as SUS 304 or SUS 316L stainless steel. Internal surfaces are polished to a mirror finish (e.g., Ra ≤ 0.4 µm) to prevent adhesion and facilitate easy, validated cleaning. The design aims to eliminate dead zones where product can accumulate .

• Precise Process Control: The system features comprehensive control over all critical parameters, including temperature (via jacketed heating/cooling), vacuum and pressure conditions, and agitator speeds for each reactor and the main homogenizer, ensuring batch-to-batch consistency .

• Vacuum and Pressure Capabilities: The system can operate under vacuum for deaeration to remove entrapped air, which is crucial for product stability, and can also handle positive pressure for specific reaction requirements .

Built for Compliance and Global Market Excellence
The system’s design, documentation, and cleanability are geared towards meeting international regulatory standards like GMP and FDA requirements.
