Description
High-Efficiency Processing for Demanding Formulations
The V-1000 is a robust system built for reliability and precision in critical manufacturing processes. It is perfectly suited for creating stable emulsions, suspensions, and solutions, ensuring product quality and repeatability from R&D through to full-scale production .
Key Technical Specifications & Operational Advantages
-
Dual Mixing System: Integrates a high-shear, rotor-stator type homogenizing turbine at the bottom of the vessel for intense emulsification and particle size reduction, alongside a slow coaxial mixing system with an optimized blade and PTFE scrapers for thorough vertical movement of the product and efficient heat transfer .
-
Precise Process Control: All mixing and homogenizing speeds are managed through variable frequency drives (inverters), allowing for perfect adaptation to different product viscosities and recipes .
-
Vacuum & Temperature Control: The vessel can operate under a vacuum circuit for deaeration, preventing oxidation and removing entrapped air. The inner jacket allows for precise heating and cooling of the product, with a maximum operating pressure of 0.49 bar .
-
Hygienic & Automated Design: Constructed with product contact parts in AISI 316 stainless steel (optional) and an AISI 304 supporting structure. The system is controlled by a 12-inch touchscreen operator panel with a Siemens PLC for recipe storage, digital parameter visualization, and continuous data logging for full traceability .
-
Industrial-Scale Capacity: Designed for large-batch processing with a capacity of up to 1000 liters, making it ideal for high-volume production lines .
Built for Compliance and Global Market Excellence
The turboemulsifier’s design, focusing on cleanability, automation, and the use of compliant materials, supports adherence to international regulatory standards like GMP. This is crucial for exporting your products to markets in Southeast Asia, Africa, the Middle East, and Latin America.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | V-1000 |
| Useful Capacity | ~100-1000 L |
| Homogenizing Turbine | Rotor/Stator type, variable speed |
| Slow Mixer | Coaxial counter-rotating system with scrapers |
| Vessel Jacket Pressure | Max 0.49 bar |
| Control System | 12″ Touchscreen with Siemens PLC |
| Construction | AISI 316 Stainless Steel (product contact) |
📜 Schedule virtual airflow visualization test.
💡 Mention your: Target market (EU/US/Global South), Active ingredient, Required throughput.
🔬 Schedule virtual factory acceptance test with our engineers.
🏷️ Request Compliance Audit: Free gap analysis with throughput simulation.
🔍Ready to Eliminate Production Bottlenecks?
💎Need Industrial Production Automation?
✅ GMP Compliance Guarantee
✅ 24/7 Multilingual Support
✅ 24-month performance guarantee
✅ Local technicians in 18 countries
📈Start small, get a free production layout designed for your growth trajectory. Scale smarter with engineering support!
📥Free line configuration for your products, throughput validation testing!
🎓Contact Specialists for Packaging Equipment:
📄 On-Demand Engineering: Product-specific configurations in 1-2 weeks.
🔧 Spare Parts Kits: Region-specific inventory for <24hr delivery.
🧼Compliance Roadmap:
- CE, EAC, ISO 9001 certifications.
- GMP-ready: 316L SS contact parts, CIP/SIP capabilities.
- ATEX options for chemical solvents.
