Description
High-Efficiency Emulsification for Demanding Cosmetic Formulations
The V-1000 is a complete system built for creating stable, fine-particle emulsions essential in modern cosmetics. Its triple coaxial agitation system ensures that even the most complex formulations achieve perfect homogeneity and exceptional physical stability, ensuring your products have a superior texture and long shelf life .
Key Technical Specifications & Operational Advantages
-
Triple Coaxial Mixing System: Integrates a high-shear homogenizing turbine for intense particle size reduction with a slow counter-rotating mixer equipped with Teflon scrapers. This ensures efficient heat transfer, prevents material from sticking to the vessel walls, and guarantees a perfectly homogeneous product.
-
Precise Process Control: All mixing and homogenizing speeds feature stepless regulation from 0 to maximum RPM, allowing for perfect adaptation to different product viscosities and recipes. This is managed via a user-friendly Touch Screen Display, which is the main element of the control system.
-
Vacuum & Temperature Control: The vessel can operate under a vacuum, which is crucial for deaerating the product, preventing oxidation, and removing entrapped air for a denser, more professional end product. The double-walled jacket allows for precise heating and cooling.
-
Hygienic & Ergonomic Design: Constructed with product contact parts in stainless steel. The vessel is tiltable for easy discharge of the finished product, and the lid is mechanically liftable. A sight glass with light allows for visual monitoring of the mixing phases.
-
Designed for Cosmetic Production: This machine is specially designed for the manufacture of stable emulsions with an extremely fine particle size, making it ideal for cosmetic milks, creams, balms, lotions, and toothpaste.
Built for Industrial Scale and Reliability
The V-1000’s robust construction and automated processes are designed for high-volume production environments. Its design supports adherence to stringent industry standards, making it a reliable choice for cosmetic manufacturers supplying global markets.
Technical Specifications
| Parameter | Specification |
|---|---|
| Total Tank Volume | 720 L |
| Working Volume | 600 L |
| Minimal Load | 150 L |
| Homogenizing Turbine Speed | 0-2800 RPM |
| Slow Mixing System Speed | 0-35 RPM |
| Total Installed Power | 34 kW |
| Control System | Touch Screen Display |
| Vessel Operation | At atmospheric pressure / under vacuum |
📜 Schedule virtual airflow visualization test.
💡 Mention your: Target market (EU/US/Global South), Active ingredient, Required throughput.
🔬 Schedule virtual factory acceptance test with our engineers.
🏷️ Request Compliance Audit: Free gap analysis with throughput simulation.
🔍Ready to Eliminate Production Bottlenecks?
💎Need Industrial Production Automation?
✅ GMP Compliance Guarantee
✅ 24/7 Multilingual Support
✅ 24-month performance guarantee
✅ Local technicians in 18 countries
📈Start small, get a free production layout designed for your growth trajectory. Scale smarter with engineering support!
📥Free line configuration for your products, throughput validation testing!
🎓Contact Specialists for Packaging Equipment:
📄 On-Demand Engineering: Product-specific configurations in 1-2 weeks.
🔧 Spare Parts Kits: Region-specific inventory for <24hr delivery.
🧼Compliance Roadmap:
- CE, EAC, ISO 9001 certifications.
- GMP-ready: 316L SS contact parts, CIP/SIP capabilities.
- ATEX options for chemical solvents.
