Description

Specialized Automation for Spray-Dispensed Liquid Products

The LR-200 Monoblock configured for spray pumps addresses a critical niche in liquid packaging: the efficient and reliable assembly of products where the closure is an integral, functional component. This machine is engineered specifically for hand sanitizers (both alcohol-based and non-alcohol formulations), pharmaceutical nasal sprays for decongestion or allergies, facial setting mists, and topical spray-on cosmetics. Its standout feature is the specialized orbital disc orienter, which gently and accurately manipulates spray pump closures—often with delicate dip tubes—and presents them perfectly for the capping head. This eliminates the jams and misalignments common when handling these non-standard closures on conventional equipment. By combining high-precision filling with this intelligent pump placement technology, the LR-200 streamlines what is typically a complex, multi-step process into a single, synchronized operation. This ensures every bottle is not only filled accurately but is also equipped with a fully functional, securely fastened spray mechanism, guaranteeing immediate customer usability and satisfaction straight off the production line.

Detailed Technical Specifications & Specialized Configuration

• Machine Type & Focus: Fully Automated, Specialized Rotary (Carousel) Monoblock. Configured with a focus on handling and applying spray pump closures, in addition to standard screw caps, for products requiring precise dispensing.

• Core Filling Technology: High-accuracy volumetric dosing system utilizing four (4) AISI 316L stainless steel piston cylinders with sanitary check valves. Provides consistent, drip-free fills for a wide viscosity range, from thin sanitizing solutions to thicker cosmetic serums intended for spray application.

• Advanced Closure Handling System: Orbital disc-type (rotary) orienting station. This sophisticated feeder is designed to handle aluminum or PET spray pump closures (actuators). It gently orients each pump, along with its attached dip tube, and reliably delivers it to the precise pick-up point for the capping head.

• Dual-Purpose Capping Station: Versatile capping head that can be tooled to securely apply both the specialized spray pump closures (pressing and/or torquing them into place) and standard plastic screw caps (PET caps). This allows for significant line flexibility.

• Construction & Hygiene Standards: All product-contact surfaces are corrosion-resistant AISI 316L / 1.4404 stainless steel, suitable for alcohol-based sanitizers, pharmaceutical ingredients, and cosmetic compounds. The GMP-ready design supports stringent cleaning protocols.

• Control & Synchronization: Centralized PLC-based control system with a multi-language HMI touchscreen. Allows for precise control over fill volume, machine indexing speed, and the timing of the orienter and capping head to ensure flawless spray pump placement.

Ideal Product Applications & Packaging Formats

• Target Products: Ideally suited for spray-dispensed liquids in healthcare, personal care, and cosmetics: hand sanitizers and antiseptic sprays, medicinal nasal sprays and saline mists, facial toners and setting sprays, body mists, spray-on sunscreens, and household cleaning sprays.

• Target Containers & Closures: Handles glass and plastic bottles designed for spray pumps. Applies aluminum or plastic (PET) spray pump closures (actuators with dip tubes). Can also be configured for standard plastic screw caps for non-spray products.

Strategic Business Advantages for Pharma and Personal Care Brands

• End-to-End Solution for Functional Packaging: This machine solves the complete packaging challenge for spray products by integrating filling with the complex task of pump assembly. This eliminates the need for a separate, downstream manual or semi-automatic pump seating station, reducing labor, floor space, and points of failure.

• Guaranteed Spray Functionality and User Experience: The precision of the orbital orienter and capping head ensures every spray pump is correctly aligned and securely fastened. This prevents leaks, ensures proper priming and spraying action, and delivers a reliable, high-quality customer experience that protects your brand reputation.

• High-Speed Production for Essential Products: The four-piston filler enables rapid throughput, which is crucial for meeting high demand for products like hand sanitizers or seasonal allergy nasal sprays. This allows you to scale production efficiently and respond quickly to market needs.

• Regulatory Compliance and Product Integrity: The GMP-ready design with 316L stainless steel construction supports compliance in regulated markets for pharmaceuticals and cosmetics. The clean, sanitary design minimizes contamination risk for sensitive products like nasal sprays.

• Operational Flexibility and Future-Proofing: While specialized for spray pumps, the platform’s core design allows it to run a wide variety of other liquid products with simple changeovers. This versatility protects your investment and allows you to adapt to future product portfolio changes. Our 24/7 global support network ensures expert assistance and rapid parts supply to keep your specialized line operational worldwide.

Automate Your Spray Product Packaging with Precision

Ready to streamline the production of your sanitizers, nasal sprays, or cosmetic mists with a machine built for the unique challenge of spray pump application? Contact our packaging automation specialists today for a detailed consultation. We can provide a free product compatibility test and line simulation to demonstrate the efficiency and reliability of the LR-200 with Spray Pump Orienter for your specific products.
