Description

The Robust Solution for Industrial & Automotive Chemical Packaging

The LR-500 Automatic Rotary Monoblock for Chemical Canisters is engineered to meet the rigorous demands of chemical manufacturing and filling facilities. Unlike standard liquid fillers, this machine is built with the resilience to handle products that are corrosive, prone to foaming, or have high viscosity. For manufacturers and contract fillers in growth regions supplying the automotive, agricultural, and industrial maintenance sectors, this monoblock offers a reliable, efficient, and safe way to scale their packaging operations while maintaining strict control over fill accuracy and spillage.

Engineered for Challenging Products: Viscosity, Foam & Corrosion

• Foam Management Technology: Specialized filling valves and controlled flow paths are designed to minimize aeration and handle foaming products (car wash soap, degreasers) effectively, preventing overflow and ensuring accurate fill volumes.

• Viscous Liquid Handling: The positive displacement rotary pumping system is capable of metering a wide range of viscosities, from thin solvents to thicker gear oils or adhesives.

• Corrosion-Resistant Construction: Critical product contact parts are manufactured from high-grade stainless steel (AISI 316L or higher) and compatible seals (EPDM, PTFE, Viton) are selected to withstand aggressive chemical attack, ensuring long service life and product purity.

Technical Specifications & Heavy-Duty Features

• Machine Type: Fully Automatic Rotary Monoblock (Filling + Capping).

• Operation: Continuous rotary motion for efficient, high-volume output.

• Filling Technology: Rotary positive displacement pump system.

• Capping Technology: Rotary capping head with integrated cap sorter and orienter for various screw caps (standard, trigger spray, dispensing caps).

• Container Compatibility: Plastic canisters (HDPE, PET), jerrycans, and small pails, typically from 0.5L to 25L.

• Output Speed: Designed for medium to high-volume production; speed depends on container size and product.

• Construction: Industrial-duty design with sealed electrical panels, drip trays, and easy-access wash-down capabilities. ATEX-rated components are available for handling flammable solvents.

• Control System: PLC with Color Touchscreen HMI for recipe management (different products/containers), production counting, and diagnostic alerts.

• Key Features: Containment shields, optional fume extraction ports, CIP (Clean-in-Place) capability, and quick-change tooling for different container formats.

Target Industries & Product Applications

This monoblock serves a wide spectrum of the chemical industry:

• Automotive & Lubricants: Engine oil, brake fluid, antifreeze, car wash shampoo, degreasers, tire shine.

• Agrochemicals: Liquid fertilizers, pesticides, herbicides, plant growth regulators.

• Industrial & Institutional Cleaning: Concentrated detergents, disinfectants, floor cleaners, degreasers.

• Construction Chemicals: Sealants, adhesives, primers, coatings, concrete additives.

• General Chemicals: Solvents, acids, alkalis, and other industrial raw materials.

Built for Safety, Compliance & Global Support

Packaging chemicals requires an unwavering commitment to safety and regulatory adherence.

• Enhanced Safety Design: Features such as sealed mechanisms, containment, and optional ATEX certification protect operators and facilities.

• Regulatory Compliance: The machine is built to relevant standards and can be supplied with certifications (CE, EAC). The GMP-ready design with CIP/SIP supports higher-grade chemical manufacturing.

• Global Support Network: We provide specialized support for chemical applications, including 24/7 technical assistance, regionally stocked chemical-resistant spare parts, and engineers trained in handling hazardous material equipment. This ensures minimal downtime for critical production lines worldwide.
