Description

Flexible, Laboratory-to-Production Solution for Sterile and Potent Liquid Formulations

Interchangeable Peristaltic Dosing Pump Head for Ultimate Flexibility.

Pneumatic Auto-Descending Nozzle for Splash-Free, Precise Filling.

In the dynamic environments of pharmaceutical development, clinical trials manufacturing, and niche cosmetic production, agility is as valuable as accuracy. The R-100 Mobile Peristaltic Line is engineered to be the ultimate agile partner, bridging the gap between laboratory development and small-scale commercial batches. Unlike traditional fixed fillers, this system embraces a modular philosophy where the core dosing element—the peristaltic pump head with its dedicated fluid path—is a removable, self-contained unit. This design philosophy directly addresses the most time-consuming aspects of small-batch processing: cleaning validation and product changeover. A manufacturer can dedicate a specific pump and tubing set to a single product, storing it safely between runs, or can quickly swap in a new pre-sterilized assembly for a different formulation. This capability is indispensable for handling potent active pharmaceutical ingredients (APIs), allergens, or strong fragrances, as it provides an unambiguous physical barrier against cross-contamination. For growing companies in Southeast Asia, Africa, and the Middle East aiming to serve multiple market niches or conduct contract manufacturing, the R-100 offers a scalable, low-risk entry into automated sterile filling that grows seamlessly with product portfolio expansion.

Technical Specifications: The Advantage of a Modular, Mobile Dosing System

• Machine Type: Semi-Automatic / Automatic, Compact Linear Dosing Station.

• Primary Applications: Ophthalmic Solutions (Eye Drops), Nasal Sprays, Ear Drops, Oral Liquid Pharmaceuticals, Vaccine Diluents, Cosmetic Ampoules & Serums, Diagnostic Reagents, E-Liquid Nicotine Shots.

• Core Technology: Mobile, Interchangeable Peristaltic Dosing Pump. The entire pump mechanism, complete with its dedicated tubing set, is mounted on a portable platform that docks securely with the main machine frame.

• Key Innovation: Dedicated Fluid Path per Product. This allows for offline preparation, cleaning, sterilization (via autoclave for the tubing set), and storage of the dosing assembly, transforming line changeover from a lengthy cleaning procedure into a simple 60-second swap.

• Nozzle System: Single filling nozzle mounted on a precision pneumatic cylinder. The cylinder provides smooth, consistent vertical movement, lowering the nozzle into the container to minimize aerosol generation and ensure accurate filling, critical for small-volume doses.

• Accuracy: Leverages the inherent accuracy of peristaltic technology, typically achieving ±0.5% to ±1% volumetric accuracy, which is essential for pharmaceutical dosing and cost control of premium ingredients.

• Container Handling: Designed for small plastic and glass vials, bottles, and dropper containers. Compatible with various stand-alone vial trays or can be integrated with a simple conveyor.

• Control System: Stand-alone digital controller with intuitive interface for setting fill volume, cycle count, and nozzle lift parameters. Simple enough for lab technicians to operate.

System Operation and Design: Prioritizing Cleanability and Product Changeover

1. Interchangeable Peristaltic Dosing Pump Head for Ultimate Flexibility: This is the system’s heart and its primary advantage. For each product, a dedicated tubing set is installed on a spare pump head. When switching from Product A to Product B, the operator simply unplugs the electrical and possibly pneumatic connections for the current pump head, lifts it off its docking station, and replaces it with the pre-prepared pump head for Product B. There is zero fluid path contact between the two products, eliminating cross-contamination risk and the need for complex internal Clean-in-Place (CIP) cycles for the pump itself. This is the gold standard for multi-product facilities.
2. Pneumatic Auto-Descending Nozzle for Splash-Free, Precise Filling: Consistency in the filling process is maintained by the automated nozzle. Upon initiation of a cycle, the pneumatic cylinder smoothly lowers the nozzle into the container until it reaches a pre-set depth. The peristaltic pump then activates, dispensing the product. This bottom-up filling method is crucial for several reasons: it prevents dripping on the container neck, reduces foaming in surfactant-based products, and minimizes the creation of airborne particulates or aerosols, which is a critical safety consideration when handling potent compounds. After filling, the nozzle retracts cleanly.

Target Applications: Beyond Eye Drops to a World of High-Value Liquids

While ideal for ophthalmic solutions, the R-100’s flexibility opens doors to numerous high-value segments:

• Clinical Trial Material (CTM) Manufacturing: Producing small, precise batches of investigational drugs where each formulation is unique and changeover speed is critical.

• Compounding & Hospital Pharmacies: Preparing personalized medications, ophthalmics, or dermatologicals in a controlled, automated manner.

• Cosmeceutical & Premium Skincare: Filling anti-aging serums, growth factor solutions, and peptide complexes where batch integrity and luxury positioning are key.

• Veterinary Pharmaceuticals: Packaging pet eye/ear medications and liquid supplements.

• Specialty Chemical & Reagent Production: Dispensing accurate volumes of calibration standards, buffer solutions, or chemical catalysts.
  For these users, the line solves the core dilemma of small-batch production: achieving automated precision and sterility assurance without the prohibitive cost and inflexibility of a dedicated, large-scale line.

The Strategic Value of Flexible, Scalable Automation for Modern Manufacturers

The R-100 Mobile Peristaltic Line represents a smart, strategic capital investment. It delivers immediate value by automating the most critical variable in liquid packaging—precision dosing—while building in long-term adaptability. Its compact footprint means it can be deployed in cleanrooms, labs, or small production suites without major facility changes. The reduction in changeover downtime directly translates to higher equipment utilization and the ability to accept a wider variety of small-run contracts. Supported by a global network that understands the needs of agile manufacturers—including rapid delivery of consumables like pharmaceutical-grade tubing and on-demand technical support—this system is more than just a filler. It is an enabler of business model flexibility, allowing manufacturers to respond to market opportunities, manage complex product portfolios, and build a reputation for impeccable quality and reliability in the fast-moving global market for specialized liquids.
