Description
Rapid, Reliable Bottling for Essential Hygiene Products
Meet fluctuating demand for essential hygiene products with consistent, high-output packaging. This LR-200 configuration is optimized for chemicals, featuring a corrosion-resistant 316L fluid path suitable for aggressive ingredients like high-concentration alcohol. The six-piston design significantly increases throughput over standard models, making it a cost-effective solution for scaling production of hand sanitizers, surface disinfectants, antiseptic wipes solution, and industrial cleaning fluids.
Key Features & Operational Benefits
-
High-Capacity Six-Piston Design: Six independent AISI 316L piston cylinders enable faster cycle times and higher output compared to 2 or 4-head models, maximizing production capacity.
-
Chemical-Resistant Construction: All product contact surfaces use AISI 316L Stainless Steel, which offers superior resistance to corrosion from alcohol, oxidizing agents, and chloride solutions found in many sanitizers and disinfectants.
-
Fast, Integrated Operation: The rotary monoblock performs filling and screw capping in a synchronized sequence, minimizing downtime and maximizing line efficiency for high-volume runs.
-
Accurate Volumetric Dosing: Positive displacement piston technology ensures precise fill volume control (±1%), reducing product giveaway and ensuring label claim compliance, which is critical for regulated antiseptics.
-
Easy Cleandown & Compliance: The sanitary design supports efficient Clean-in-Place (CIP) procedures. The machine is built to support GMP, ISO 9001, and CE/EAC standards, with optional ATEX ratings for handling flammable solvents.
Technical Specifications: LR-200 for Antiseptics & Sanitizers
| Feature | Specification |
|---|---|
| Machine Type | Rotary (Carousel) Monoblock Filler & Capper |
| Filling Technology | Volumetric Piston Dosing (6 cylinders) |
| Piston Material | AISI 316L Stainless Steel (Chemical Resistant) |
| Target Products | Hand Sanitizers (Alcohol-based), Antiseptic Solutions, Disinfectants, Liquid Soaps, Chemical Cleaners |
| Primary Container | Plastic Bottles (PET, HDPE) |
| Cap Type | Plastic Screw Caps (e.g., flip-top, pump dispensers) |
| Cap Handling | Vibratory Cap Orienter & Sorter |
| Key Advantage | Higher Throughput Configuration |
| Compliance (Standard) | GMP-ready, CIP-capable, CE/EAC, ISO 9001 |
| Special Options | ATEX-rated version for flammable liquids (high-proof alcohol) |
Global Support for FMCG & Chemical Producers
-
Rapid Deployment: Designed for quick installation and commissioning, with support hubs in Dubai, Hanoi, and Lagos to facilitate fast market entry.
-
High-Uptime Design: Built for continuous runs with easy-access maintenance and region-specific spare parts kits for less than 24-hour delivery in key areas.
-
Output Guarantee: Comes with a 24-month performance guarantee and a free efficiency audit promising a 15% output improvement.
📜 Schedule virtual airflow visualization test.
💡 Mention your: Target market (EU/US/Global South), Active ingredient, Required throughput.
🔬 Schedule virtual factory acceptance test with our engineers.
🏷️ Request Compliance Audit: Free gap analysis with throughput simulation.
🔍Ready to Eliminate Production Bottlenecks?
💎Need Industrial Production Automation?
✅ GMP Compliance Guarantee
✅ 24/7 Multilingual Support
✅ 24-month performance guarantee
✅ Local technicians in 18 countries
📈Start small, get a free production layout designed for your growth trajectory. Scale smarter with engineering support!
📥Free line configuration for your products, throughput validation testing!
🎓Contact Specialists for Packaging Equipment:
📄 On-Demand Engineering: Product-specific configurations in 1-2 weeks.
🔧 Spare Parts Kits: Region-specific inventory for <24hr delivery.
🧼Compliance Roadmap:
- CE, EAC, ISO 9001 certifications.
- GMP-ready: 316L SS contact parts, CIP/SIP capabilities.
- ATEX options for chemical solvents.
