Description
Optimize Your Box Handling with Precision-Guided Conveying
The K-10 Plate Turn Conveyor is engineered to solve the challenge of managing box flow in complex layouts. It is particularly useful for changing the direction of your packaging line in a confined space. The integrated side guides are crucial for maintaining the orientation and stability of cardboard boxes, shipping cases, and product cartons, making this system indispensable for distribution centers, post-packaging areas, and assembly operations .
Key Features and Technical Advantages
-
Robust Plate Top Surface: The interlocking plate belt offers a stable, non-flexible conveying path superior to fabric belts for handling heavier or unstable box loads .
-
Fully Adjustable Guide Rails: The side guides can be easily repositioned to accommodate a wide range of box sizes and shapes, ensuring versatility for different products .
-
Reliable Turn Operation: Engineered for smooth performance, allowing boxes to navigate the curve without stopping or jamming, which maintains your line’s efficiency.
-
Hygienic Design Options: Available with frames and contact parts made from stainless steel (AISI 304 or 316L) to meet hygiene standards for food, pharmaceutical, and cosmetic applications .
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | K-10 |
| Conveyor Type | Plate Turn Conveyor with Side Guides |
| Track Width | 245 mm |
| Conveyor Speed | Adjustable, ~4.2 m/min |
| Power Consumption | 0.18 kW |
| Voltage | 220V |
| Frame Material | Powder-coated carbon steel or Stainless Steel |
Industries and Applications
This conveyor is essential for streamlining operations in multiple sectors:
-
Logistics & E-commerce: For directing cardboard boxes and shipping totes in warehouses and distribution centers .
-
Post-Packaging Lines: Transporting and turning packaged goods from the end of a production line to palletizing stations .
-
General Manufacturing & Assembly: Moving boxed components and finished products along an assembly line.
Built for Reliability in Global Industrial Applications
Designed for the demanding requirements of international markets, the K-10 conveyor focuses on durability and ease of integration. Its robust design ensures consistent performance, helping to streamline operations in logistics and production facilities worldwide, including those in your target markets.
