Description
High-Speed Rotary Dosator with Piston Cylinders for Filling Household and Automotive Chemicals: LRF-100
Robust Packaging for Demanding Chemical Applications
The LRF-100 High-Speed Rotary Dosator addresses the specific needs of manufacturers packaging household and automotive chemicals. These products often have varying viscosities and can be abrasive or corrosive. The piston cylinder technology is particularly suited for this task, as it is designed to handle viscous liquids and pastes that cannot flow on their own . The rotary design allows for continuous, high-volume filling, making it significantly faster than linear systems for large-scale production runs. This machine is perfectly suited for contract packagers and branded manufacturers in global markets where output, reliability, and product integrity are critical.
Technical Specifications & Performance Data
| Specification Category | Details |
|---|---|
| Operation Type | Automatic, Rotary |
| Filling Technology | Piston Cylinders |
| Typical Products | Detergents, Liquid Soaps, Lubricants, Motor Oils, Cleaning Agents |
| Production Speed | 80-120 containers per minute |
| Filling Accuracy | ±0.5% |
| Control System | Programmable Logic Controller (PLC) with Touchscreen HMI |
| Construction Materials | AISI 304 / 316L Stainless Steel (corrosion-resistant for chemicals) |
| Power Requirements | 220V — 380V / 50Hz |
Key Features & Operational Benefits
-
Precision Piston Filling: The core piston mechanism provides exceptional volumetric accuracy, ensuring consistent fill volumes and minimizing product giveaway, which is crucial for cost control with chemical products .
-
High-Speed Rotary Platform: The continuous rotary motion enables high-throughput production, allowing for the filling of hundreds of containers per minute, which maximizes production line efficiency.
-
Hygienic & Corrosion-Resistant Design: The use of stainless steel (AISI 304/316L) on all product contact surfaces provides resistance to corrosive chemicals and allows for easy cleaning, ensuring compliance with industry standards .
-
Durability for Challenging Products: The robust construction and piston technology are designed to handle a wide range of product viscosities, from thin liquids to thick, abrasive pastes, without compromising performance .
Industries & Application Solutions
-
Household Chemical Production: Perfect for filling liquid laundry detergents, dish soaps, all-purpose cleaners, and disinfectants.
-
Automotive Chemical Industry: Ideal for packaging engine oils, brake fluids, antifreeze, car shampoos, and degreasers.
