Description
High-Throughput, Precision Labeling for Small Pharmaceutical Vials
Advanced Rotary Feeding and Application System.
Purpose-Built for Critical Pharmaceutical and Biotech Applications.
The LL-1000 addresses the critical need for speed and accuracy in pharmaceutical packaging, where large batches of small-volume containers must be labeled flawlessly for patient safety and regulatory compliance. Its design prioritizes gentle yet precise handling of delicate glass vials, ensuring zero breakage and perfect label placement every time.
Advanced Rotary Feeding and Application System
This machine utilizes a continuous-motion rotary mechanism for superior efficiency:
-
Rotary Feeding Wheel: Gently accepts vials from an infeed conveyor and transports them in a stable, controlled circular path to the labeling station.
-
High-Precision Label Applicator: A specialized applicator head designed for small labels accurately dispenses and applies self-adhesive labels with minimal drag or misalignment.
-
Integrated Conveyor & Output Table: A synchronized conveyor system carries vials into the rotary wheel and delivers finished, labeled vials to an output accumulation table or directly to downstream packaging equipment.
-
Vision Inspection Ready: The system can be equipped with automated vision inspection cameras to verify label presence, placement, and legibility (barcode/text) in-line, providing 100% quality control.
Technical Specifications & GMP-Ready Design
| Parameter | Specification / Description |
|---|---|
| Machine Type | Automatic, High-Speed Rotary Labeling System |
| Target Containers | Small pharmaceutical vials (penicillin, insulin, vaccine, diagnostic vials) |
| Label Type | Clear and opaque self-adhesive (pressure-sensitive) labels |
| Feeding System | Rotary feeding wheel with star guides |
| Core Components | Rotary wheel, label applicator, main conveyor, output table, control cabinet |
| Construction | GMP-ready: 316L Stainless Steel contact parts, easy-clean design, minimal particle generation |
| Control & Validation | PLC with HMI; supports IQ/OQ/PQ documentation and 21 CFR Part 11 compliance (optional) |
| Integration | Designed for direct integration into automatic sterile filling and capping lines |
Purpose-Built for Critical Pharmaceutical and Biotech Applications
-
Pharmaceuticals: Primary labeling of antibiotic vials (penicillin), insulin cartridges, hormone vials, and injectable drug containers.
-
Biotechnology: Labeling clinical trial samples, biologic drug vials, and diagnostic reagent containers.
-
Contract Manufacturing (CDMO): An ideal flexible system for high-mix or high-volume production environments serving multiple clients.
Fully Automated, High-Speed Operation
Operation is designed for maximum uptime and minimal operator intervention:
-
Infeed: Vials are automatically fed into the rotary wheel via a conveyor.
-
Transport & Application: The rotary wheel positions each vial under the applicator head. A sensor triggers the precise application of the label.
-
Smoothing & Discharge: An integrated smoothing mechanism (brush or pad) ensures perfect adhesion. The vial is then discharged onto the output conveyor/table.
-
Integration: The system can be linked with upstream vial washers/fillers and downstream cappers and packagers.
The Reliable Engine for Your Sterile Fill-Finish Line
The LL-1000 is more than a labeler; it is a critical productivity module within an integrated aseptic processing line. Its reliability, speed, and compliance-focused design help ensure your entire fill-finish operation meets output targets while adhering to the strictest quality and regulatory standards of global health authorities.
Built for Global Compliance and Supported Locally
Engineered for the highly regulated global pharmaceutical market:
-
Certifications & Standards: Designed to facilitate validation and meet cGMP, GAMP 5, and ISO 14644 standards for cleanrooms. Compliant with CE, EAC, and ISO 9001.
-
Global Support Network: 24/7 multilingual pharmaceutical-grade technical support. Rapid service and GMP-compliant spare parts kits from regional hubs in Dubai (MENA), Hanoi (Southeast Asia), and Lagos (Africa).
-
Validation & Documentation: Full Factory Acceptance Test (FAT) and Site Acceptance Test (SAT) support. Comprehensive validation documentation packages (DQ, IQ, OQ, PQ) are available to streamline your qualification process.
Fully Automated, High-Speed Operation.
The Reliable Engine for Your Sterile Fill-Finish Line.
