Description
Engineered for Maximum Output: The Power of 12 Synchronized Piston Nozzles
In the competitive world of industrial and consumer chemical manufacturing, throughput is a direct driver of profitability and market responsiveness. The R-200 line addresses this head-on with its high-density array of 12 independent piston dosing nozzles. This design allows for the simultaneous filling of 12 containers per cycle, drastically reducing the cycle time per bottle and enabling output speeds that can exceed 200 bottles per minute for standard sizes, depending on viscosity and volume. Each piston is engineered for precision volumetric displacement, ensuring consistent fills from the first bottle to the ten-thousandth, which is critical for maintaining label claim accuracy and minimizing costly product giveaway. The system is managed by an advanced PLC that synchronizes the filling block with the downstream automatic capping machine and label applicator, creating a seamless, high-speed flow from empty container to finished, saleable product. The integrated vibratory orienter ensures a continuous, jam-free supply of caps to the capping heads, eliminating a common manual bottleneck and further maximizing line uptime. This configuration is particularly valuable for high-volume contract manufacturers, large-brand private label producers, and any chemical plant looking to optimize their packaging floor space with a single, highly efficient line instead of multiple slower machines.
Technical Specifications: Robust Design for Demanding Chemical Environments
| System Module | Core Technology & Features | Performance Specifications & Capabilities |
|---|---|---|
| Filling Module | 12-Nozzle Piston Cylinder Block. 316L Stainless Steel & PTFE wetted parts. Individual cylinder adjustment. CIP/SIP capable. No-drip, chemical-resistant valves. | Volume Range: 100 ml to 5,000 ml (customizable). Accuracy: ±0.5% or better. Theoretical Speed: Can support outputs of 200+ BPM (bottles per minute). Viscosity: Handles thin to highly viscous products. |
| Capping Module | Linear or Rotary Automatic Capper. Servo-driven torque control. Paired with vibratory bowl cap orienter/feeder. | Cap Types: Screw caps, flip-tops, trigger sprayers. Torque Accuracy: Programmable and repeatable. Cap Handling: Automated feeding and sorting. |
| Labeling Module | Automatic Pressure-Sensitive Label Applicator. Models for round body or front/back labeling on flat containers. | Label Accuracy: ±0.5 mm. Flexibility: Quick changeover for different container shapes. Speed: Matches high line output. |
| Construction & Safety | Heavy-duty stainless steel frame. Corrosion-resistant epoxy paint. ATEX-rated components available for explosive atmospheres (solvents). | Hygiene: GMP-ready design, easy wash-down. Safety: Options for inert gas purging, explosion-proof motors. |
| Control System | Industrial PLC with 15″ Multi-Language Touchscreen HMI. Recipe management for 100+ products. Production and OEE dashboard. | User Interface: Intuitive controls for operators. Connectivity: Ethernet/IP for factory integration. Data Logging: Tracks output, efficiency, downtime. |
Universal Chemical Industry Applications: From Household Cleaners to Agro-Chemicals
The R-200 12-nozzle line is engineered as a universal workhorse for the global chemical industry:
-
Household & Institutional Cleaning: High-speed filling of liquid laundry detergents, dish soaps, all-purpose cleaners, floor cleaners, and disinfectants.
-
Automotive & Industrial Chemistry: Precision packaging of engine oils, coolants, brake fluids, windscreen washer fluids, degreasers, lubricants, and anti-corrosion sprays.
-
Construction & Industrial Chemicals: Handling adhesives, sealants, liquid nails, concrete additives, paints, and coatings.
-
Agricultural Chemistry (Agro-Chem): Filling liquid fertilizers, herbicides, pesticides, and plant growth regulators.
-
Alkaline & Specialty Chemicals: Designed with compatible materials for caustic sodas, acid-based cleaners, and other aggressive chemical formulations.
The Competitive Edge: Guaranteed Uptime, Global Compliance & Localized Support for Industrial Growth
For a high-capacity line, uptime is synonymous with revenue. We support your critical investment with an unmatched global framework. The line is built on a platform compliant with CE, EAC, and ISO 9001, and its 316L SS construction with CIP makes it GMP-ready for chemical products where hygiene is paramount. Critically, ATEX-certified versions are available for handling flammable solvents, a non-negotiable requirement for many chemical plants. We ensure seamless integration into any facility with full voltage customization (110V to 480V). Our operational promise is robust: on-site commissioning in under 72 hours in key regions, 24/7 multilingual remote support (EN/RU/AR/ES), and region-specific spare parts kits stocked in our hubs in Dubai, Hanoi, and Lagos for under 24-hour emergency delivery. We begin the partnership with a free product compatibility and throughput validation test using your chemicals. Our «On-Demand Engineering» can tailor nozzle materials or cylinder sizes within 1-2 weeks. All these services are underpinned by our definitive 24-month performance guarantee, ensuring the R-200 12-nozzle line becomes the most reliable and productive asset in your factory.
📜 Schedule virtual airflow visualization test.
💡 Mention your: Target market (EU/US/Global South), Active ingredient, Required throughput.
🔬 Schedule virtual factory acceptance test with our engineers.
🏷️ Request Compliance Audit: Free gap analysis with throughput simulation.
🔍Ready to Eliminate Production Bottlenecks?
💎Need Industrial Production Automation?
✅ GMP Compliance Guarantee
✅ 24/7 Multilingual Support
✅ 24-month performance guarantee
✅ Local technicians in 18 countries
📈Start small, get a free production layout designed for your growth trajectory. Scale smarter with engineering support!
📥Free line configuration for your products, throughput validation testing!
🎓Contact Specialists for Packaging Equipment:
📄 On-Demand Engineering: Product-specific configurations in 1-2 weeks.
🔧 Spare Parts Kits: Region-specific inventory for <24hr delivery.
🧼Compliance Roadmap:
- CE, EAC, ISO 9001 certifications.
- GMP-ready: 316L SS contact parts, CIP/SIP capabilities.
- ATEX options for chemical solvents.
