Description

Precision Filling for Aggressive Construction Chemicals

Engineered for Challenging Liquids

The LGF-20 addresses the unique challenges of packaging construction chemicals. Its submerged nozzle fills containers from the bottom up, while the diaphragm pump provides steady transfer of viscous and abrasive fluids. This combination is essential for maintaining product integrity and filling accuracy.

Technical Highlights and Key Features

• Submerged Nozzle (Dip-Pipe) Filling: The core feature that sets this system apart. The lance descends into the container, and filling occurs at the bottom, displacing air upwards with minimal turbulence to control foam and fumes.

• Diaphragm Pump System: A robust pump technology, often air-operated (AODD pump), is ideal for handling thick, abrasive, or shear-sensitive liquids without damage. It provides a consistent flow rate for accurate dosing.

• Gravity-Assisted Dosing: The system utilizes a gravimetric (weight-based) or volumetric principle for high fill-volume accuracy, ensuring each container meets exact specifications.

• Corrosion-Resistant Construction: Contact parts are constructed from materials such as stainless steel (e.g., 304 or 316) or PTFE-coated components to withstand aggressive chemicals.

• Automated Control System: features a Programmable Logic Controller (PLC) with an HMI touchscreen for easy recipe management, ensuring consistent fill volumes and repeatable performance across different products.

Industries and Applications
The LGF-20 is specialized for sectors requiring handling of difficult liquids:

• Construction Chemicals: Filling liquid sealants, polyurethane foams, epoxy adhesives, tile adhesives, and waterproofing coatings.

• Industrial Chemicals: Packaging lubricants, greases, and industrial adhesives.

Why Choose This System?

• Foam Control: Submerged filling is the most effective method for preventing foam formation in sensitive chemicals.

• Handling High Viscosity: The diaphragm pump is uniquely suited for pumping thick products that would challenge other pump types.

• Reduced Waste: Precision filling eliminates overfilling and underfilling, leading to significant product and cost savings.

• Durability: Built with chemically resistant materials for a long service life in corrosive environments.
