Description
Precision at Your Fingertips for Critical Applications
Designed for applications where every fill and every seal must be perfect, this station puts control in the operator’s hands without sacrificing mechanical accuracy. The trigger-operated capping head allows the operator to precisely initiate the capping cycle, ensuring perfect alignment and consistent closure torque for leak-proof seals. The submerged filling nozzle gently dispenses product below the surface level to prevent aeration, oxidation, or foaming of sensitive liquids.
Key Features & Operational Benefits
-
Trigger-Activated Four-Roller Capping Head: The operator triggers the capping cycle, allowing for visual verification of cap placement. The four-roller mechanism applies even, concentric pressure for a consistent and secure tamper-evident seal on plastic screw caps.
-
Gentle, Submerged Nozzle Filling: The piston cylinder is equipped with a nozzle that descends into the container, filling from the bottom up. This is critical for foaming products, volatile solvents, perfumes, and oxygen-sensitive formulations.
-
Compact, Semi-Automatic Design: An ideal upgrade from fully manual processes. The operator presents each container, ensuring flexibility for short runs, frequent changeovers, or handling delicate/odd-shaped bottles.
-
Precision Piston Dosing: The core AISI 316L stainless steel piston ensures volumetric filling accuracy for a vast range of liquid viscosities, from thin alcohols to thick creams.
-
Hygienic & Compliant Build: All product contact surfaces are 316L stainless steel, supporting easy cleaning and GMP-ready practices. The compact design fits easily into lab hoods or small clean zones.
Technical Specifications: LR-200 Compact Station with Trigger Capper
| Feature | Specification |
|---|---|
| Machine Type | Compact Semi-Automatic Benchtop/Station |
| Operation Mode | Semi-Automatic (Operator presents container & triggers capping) |
| Filling Technology | Volumetric Piston Dosing (1 cylinder) with Submerged Nozzle |
| Capping Technology | Trigger-Activated, Four-Roller Screw Capping Head |
| Piston/Cap Material | AISI 316L Stainless Steel / Plastic Screw Caps |
| Configuration | Integrated Receiving Tank, Submerged Filling Nozzle, Trigger Capper |
| Primary Applications | High-Value Cosmetics, Perfumes, Essential Oils, Specialty Chemicals, Pharmaceutical Samples |
| Ideal Use Case | R&D, QC Labs, Pilot Batches, Small-Scale Production, Contract Packaging Samples |
| Compliance (Standard) | GMP-ready, CIP-capable, CE/EAC, ISO 9001 |
Support for Precision Manufacturing
-
Validation Ready: The consistent, programmable operation supports method validation for laboratory and small-batch GMP work.
-
Global Expert Support: Access the same network of technical hubs and 24-month performance guarantee.
-
Low-Barrier Automation: An ergonomic and affordable step into precision filling and capping automation.
📜 Schedule virtual airflow visualization test.
💡 Mention your: Target market (EU/US/Global South), Active ingredient, Required throughput.
🔬 Schedule virtual factory acceptance test with our engineers.
🏷️ Request Compliance Audit: Free gap analysis with throughput simulation.
🔍Ready to Eliminate Production Bottlenecks?
💎Need Industrial Production Automation?
✅ GMP Compliance Guarantee
✅ 24/7 Multilingual Support
✅ 24-month performance guarantee
✅ Local technicians in 18 countries
📈Start small, get a free production layout designed for your growth trajectory. Scale smarter with engineering support!
📥Free line configuration for your products, throughput validation testing!
🎓Contact Specialists for Packaging Equipment:
📄 On-Demand Engineering: Product-specific configurations in 1-2 weeks.
🔧 Spare Parts Kits: Region-specific inventory for <24hr delivery.
🧼Compliance Roadmap:
- CE, EAC, ISO 9001 certifications.
- GMP-ready: 316L SS contact parts, CIP/SIP capabilities.
- ATEX options for chemical solvents.
