Description
ACM-300: High-Speed Automatic Rotary Capping Machine
The ACM-300 represents the pinnacle of efficiency and reliability in automated packaging capping solutions. It is built to meet the rigorous demands of modern production environments, ensuring leak-proof seals and perfect package presentation for your customers.
Our rotary capper utilizes a sophisticated synchronization system to apply caps to containers as they move continuously on the conveyor line, maximizing speed without sacrificing accuracy. The machine is constructed with hygiene and easy maintenance as a priority, featuring easy-to-clean surfaces and quick-change parts to minimize downtime during product switchovers.
Key Features and Benefits
-
Broad Compatibility: Effortlessly handles a diverse array of cap types (snap-on, screw, trigger sprayers) and lid diameters, making it ideal for contract packagers or facilities with multiple product lines.
-
Precise Torque Control: Incorporates an adjustable, closed-loop torque management system to ensure each cap is applied with the exact required force. This prevents under-tightening (which can lead to leaks) and over-tightening (which can damage caps or containers).
-
Robust GMP Construction: Built with a rigid stainless steel frame and food-grade contact parts, the ACM-300 is designed for easy cleaning and compliance with Good Manufacturing Practice (GMP) standards, which is crucial for pharmaceutical, cosmetic, and food applications.
-
High-Speed Performance: Engineered for continuous operation on high-volume production lines, dramatically increasing your output and reducing reliance on manual labor.
-
User-Friendly HMI: Features a simple, intuitive touch-screen interface for easy setup, operation, and monitoring of all machine functions, including speed, torque, and production counts.
Technical Specifications
| Specification Category | Details |
|---|---|
| Machine Model | ACM-300 Rotary Capping Machine |
| Cap Diameter Range | 15 mm to 120 mm |
| Production Speed | Up to 60-80 containers per minute |
| Torque Adjustment Range | 0.5 Nm to 25 Nm |
| Power Supply | 220V / 50Hz |
| Air Pressure | 6-8 bar |
| Machine Dimensions (LxWxH) | 2000 x 1500 x 1800 mm |
| Weight | Approximately 1200 kg |
Industries and Applications
The ACM-300 is perfectly suited for:
-
Pharmaceuticals: Sealing bottles for syrups, tablets, and sterile solutions.
-
Cosmetics & Personal Care: Capping bottles for shampoos, lotions, creams, and serums.
-
Food & Beverage: Applying lids to jars, bottles for sauces, drinks, and condiments.
-
Chemicals: Sealing containers for household cleaners, automotive chemicals, and lubricants.
📜 Schedule virtual airflow visualization test.
💡 Mention your: Target market (EU/US/Global South), Active ingredient, Required throughput.
🔬 Schedule virtual factory acceptance test with our engineers.
🏷️ Request Compliance Audit: Free gap analysis with throughput simulation.
🔍Ready to Eliminate Production Bottlenecks?
💎Need Industrial Production Automation?
✅ GMP Compliance Guarantee
✅ 24/7 Multilingual Support
✅ 24-month performance guarantee
✅ Local technicians in 18 countries
📈Start small, get a free production layout designed for your growth trajectory. Scale smarter with engineering support!
📥Free line configuration for your products, throughput validation testing!
🎓Contact Specialists for Packaging Equipment:
📄 On-Demand Engineering: Product-specific configurations in 1-2 weeks.
🔧 Spare Parts Kits: Region-specific inventory for <24hr delivery.
🧼Compliance Roadmap:
- CE, EAC, ISO 9001 certifications.
- GMP-ready: 316L SS contact parts, CIP/SIP capabilities.
- ATEX options for chemical solvents.
