Precision Engineering for Diverse Liquid Products: From Shampoos to Industrial Cleaners
The R-200 line is the epitome of adaptive engineering, built to handle the unique physical characteristics of various liquid products. Its advanced linear piston filling technology delivers unparalleled volumetric accuracy for products with different viscosities—from thin, water-like detergents and screen washes to thick, creamy shampoos and lotions. The system is meticulously calibrated to manage foaming liquids and surfactants without causing excessive froth or air inclusion, ensuring every bottle is filled to the exact specified volume with zero overflow waste. This capability extends to a wide industrial spectrum, including automotive care liquids (shampoos, waxes, tire cleaners), building and industrial chemicals (concentrated cleaners, degreasers), and even agrochemicals, provided material compatibility is confirmed. The labeling module is equally versatile, designed to apply labels with precision on both round and flat-sided containers, accommodating the diverse packaging styles of the personal care and home care industries.
Core Technical Specifications & Unmatched Performance
| System Module | Core Technology & Features | Performance Specifications & Capabilities |
|---|---|---|
| Filling Module | Linear Piston Filler. 316L Stainless Steel & PTFE wetted parts. CIP/SIP capable. No-drip, self-sealing nozzles. | Volume Range: 50 ml to 5,000 ml (customizable). Accuracy: ±0.5% or better. Speed: Up to 150 containers per minute (dependent on volume and product). Handles low to high-viscosity liquids. |
| Capping Module | Linear Automatic Spindle Capper. Adjustable torque control. Handles screw caps, flip-tops, trigger pump heads, and snap-on lids. | Cap Diameter Range: 15 mm to 120 mm. Torque Accuracy: Programmable and repeatable. Integration: «No bottle, no cap» sensor interlocks. |
| Labeling Module | Automatic Roll-Fed Label Applicator. High-resolution servo drive. Applicator heads for front/back/wrap-around labeling. | Label Accuracy: ±0.5 mm. Max Label Width: 180 mm. Application Speed: Synchronized with line pace. Optional vision inspection. |
| Conveyor & Frame | Stainless steel plate-top chain conveyor. Modular, heavy-duty frame. Tool-less guide rail adjustments for quick format change. | Flexibility: Easy adaptation for different bottle shapes/sizes. Hygiene: Fully wash-down capable design. |
| Control System | Centralized PLC with 15″ Color Touchscreen HMI (Multi-language). Industrial IoT-ready for data monitoring. | User Interface: Intuitive recipe management. Data Logging: OEE, production counts, downtime tracking. Connectivity: Ethernet/IP, Profinet. |
A Line Built for Compliance, Efficiency, and Global Scalability
We engineer the R-200 to be more than a machine; it’s a compliant, future-proof asset. The line is designed to be GMP-ready, facilitating validation protocols (IQ, OQ, PQ) for sensitive industries. It comes standard with a foundation for CE, EAC, and ISO 9001 certifications, and ATEX-rated versions are available for handling flammable solvents in chemical applications—a testament to its core platform’s robustness. Understanding the challenges of global operation, we build in voltage customization (110V to 480V) and provide multi-language HMIs (English, Spanish, Arabic, etc.) as standard.
Our global operational support is a key differentiator: With regional service hubs in Dubai (MENA), Hanoi (Southeast Asia), and Lagos (Africa), we ensure expert support is never far away. We commit to on-site commissioning within 72 hours in key regions and offer region-specific spare parts kits for under 24-hour delivery to minimize your downtime. Our 24/7 remote monitoring and multilingual technical support (EN/RU/AR/ES) provide an unparalleled safety net for your operations, whether you are in Latin America, Eastern Europe, or Southeast Asia.
Your Partner for Growth: From Free Layout Design to 24/7 Support
Your investment journey with the R-200 begins with a collaborative partnership. We offer a free, no-obligation production line configuration and throughput validation test based on your specific products. Our engineers will design a custom factory layout optimized for your current space and future growth trajectory. You can schedule a virtual factory acceptance test (FAT) to see your configured line in action before commissioning.
We stand behind our technology with a comprehensive 24-month performance guarantee and offer a free efficiency audit with a guaranteed 15% output improvement analysis for existing operations looking to upgrade. For unique product challenges, our «On-Demand Engineering» service delivers product-specific machine configurations within 1-2 weeks.
📜 Schedule virtual airflow visualization test.
💡 Mention your: Target market (EU/US/Global South), Active ingredient, Required throughput.
🔬 Schedule virtual factory acceptance test with our engineers.
🏷️ Request Compliance Audit: Free gap analysis with throughput simulation.
🔍Ready to Eliminate Production Bottlenecks?
💎Need Industrial Production Automation?
✅ GMP Compliance Guarantee
✅ 24/7 Multilingual Support
✅ 24-month performance guarantee
✅ Local technicians in 18 countries
📈Start small, get a free production layout designed for your growth trajectory. Scale smarter with engineering support!
📥Free line configuration for your products, throughput validation testing!
🎓Contact Specialists for Packaging Equipment:
📄 On-Demand Engineering: Product-specific configurations in 1-2 weeks.
🔧 Spare Parts Kits: Region-specific inventory for <24hr delivery.
🧼Compliance Roadmap:
- CE, EAC, ISO 9001 certifications.
- GMP-ready: 316L SS contact parts, CIP/SIP capabilities.
- ATEX options for chemical solvents.
