Description

The Automated Workhorse for Growing Beverage Brands

The LR-400 Universal Automatic Monoblock represents the next step in production scalability for beverage manufacturers. Engineered for businesses that have outgrown manual or semi-automatic bottling, this machine automates the entire sequence from empty bottle infeed to sealed product discharge. Its «universal» designation comes from its robust design and adjustable components, making it suitable for various carbonated products packaged in standard glass bottles. For entrepreneurs in growth markets, this machine offers a perfect balance of increased automation, manageable investment, and the proven durability required for continuous operation.

Streamlined Automatic Operation: From Infeed to Sealed Bottle

The LR-400 Universal operates on a seamless, automated workflow:

1. Automatic Bottle Feeding: Empty glass bottles are fed via a conveyor system into the machine’s bottle orienter. This orienter ensures all bottles are correctly aligned for the filling process.

2. Precision Filling: The aligned bottles are automatically indexed under the filling valves. The machine utilizes a controlled filling system suitable for carbonated products, ensuring accurate fill volumes while managing foam.

3. Automatic Crown Capping: Immediately after filling, bottles are transported to the integrated automatic crowning station. Here, aluminum crown caps (crown corks) are sorted, oriented, and mechanically crimped onto the bottles with consistent force.

4. Discharge: The sealed bottles are conveyed out of the monoblock, ready for downstream processes like labeling, pasteurization, or packaging.

Technical Specifications & Universal Design

• Machine Type: Fully Automatic Inline Monoblock (Integrated Conveyor + Filling + Crowning).

• Operation: Fully automatic, with PLC-controlled sequence.

• Key Components: Includes infeed conveyor, bottle orienting starwheel, filling station, automatic crown capper.

• Filling Technology: Pressure-controlled filling system for carbonated beverages (isobaric principle or similar).

• Capping Technology: Fully automatic crown cap (pilfer-proof cap) sorter, orienter, and crimping head.

• Output Speed: Designed for medium-scale production, with outputs typically ranging from 1,000 to 6,000 bottles per hour (BPH), depending on configuration.

• Bottle Compatibility: Standard glass bottles (330ml, 500ml, 1L) with standard crown neck finishes.

• Construction: Industrial-grade frame with AISI 304 Stainless Steel on product contact areas. Designed for easy access and cleaning.

• Control System: Central PLC with an intuitive HMI (Human-Machine Interface) for controlling speed, fill time, and monitoring production counts and faults.

• Key Features: Minimal floor space requirement, reduced labor dependency, consistent sealing quality, and robust construction for demanding environments.

Versatile Applications for Carbonated Drinks

This universal monoblock is engineered to handle the diversity of the modern beverage market:

• Sweet Carbonated Drinks (CSD): Colas, lemonades, orange sodas, and other flavored soft drinks.

• Craft & Traditional Beverages: Craft beer, kvass, cider, hard seltzers.

• Sparkling Waters: Naturally and artificially carbonated sparkling water.

Engineered for Reliability & Global Support

Investing in the LR-400 Universal means investing in your production future with a partner committed to your uptime. We complement the machine’s robust engineering with a support network tailored for global operations:

• Scalable Automation: It provides a significant productivity leap from semi-automatic systems, preparing your plant for higher demand.

• Reduced Operational Complexity: Automated feeding and capping increase consistency and free up skilled labor for supervision and quality control.

• Comprehensive Service Ecosystem: As with all our equipment, the LR-400 Universal is backed by our 24/7 multilingual technical support, regional service hubs (Dubai, Hanoi, Lagos), and fast spare parts delivery to keep your line running.

• Compliance Ready: The machine is built with hygienic design principles (GMP-ready, CIP capable) and can be supplied with relevant international certifications (CE, EAC) to support your market access.
