ACM-300: High-Speed Rotary Capping with Orienter
The ACM-300 Rotary Capper sets a new standard for efficiency and reliability on the packaging line. It is engineered to handle the complex task of correctly aligning and applying specialized closures like flip-top dosing caps and trigger sprayers, which are essential for user-friendly liquid products.
This machine utilizes a rotary indexing system for continuous motion operation, maximizing throughput. The integrated orienter ensures that non-symmetrical caps are perfectly positioned before application. With precise torque control, the ACM-300 guarantees that each cap is sealed securely—preventing leaks from under-tightening and avoiding cap damage from over-tightening. Its robust construction ensures durability and easy maintenance, making it a long-term asset for demanding production environments.
Key Features and Benefits
-
Precision Orienting System: Automatically detects and correctly aligns dosing caps and trigger sprayers for consistent, perfect placement on every container.
-
Versatile Cap Handling: Efficiently manages a wide range of complex closure types, including flip-top caps (dosing caps) and trigger sprayers, allowing for flexible production scheduling.
-
Accurate Torque Control: Features an adjustable torque system to apply the exact required force, ensuring a secure seal and protecting both caps and containers from damage.
-
High-Speed Rotary Design: Engineered for continuous operation, this machine significantly increases packaging line throughput compared to semi-automatic or linear systems.
-
GMP-Compliant Construction: Built with hygiene in mind, featuring easy-to-clean surfaces and a design that adheres to industry standards for pharmaceutical and cosmetic production.
📊 Technical Specifications & Applications
Technical Specifications Table
| Specification | Details |
|---|---|
| Machine Model | ACM-300 Rotary Capping Machine |
| Compatible Closures | Dosing Caps, Trigger Sprayers |
| Application Speed | Up to 80-100 containers per minute |
| Container Diameter Range | 8 mm — 42 mm |
| Power Supply | 220 V, 50 Hz, 1-Phase |
| Air Pressure | 6 — 8 bar |
| Machine Dimensions | 2.800 x 1.650 x 2.400 mm |
| Weight | Approximately 1300 kg |
Industries and Applications
The ACM-300 is ideally suited for packaging lines in:
-
Cosmetics & Personal Care: Capping bottles for shampoos, lotions, and liquid soaps with flip-top or sprayer closures.
-
Pharmaceuticals: Sealing bottles for medicated syrups, disinfectants, and other liquid treatments.
-
Household & Industrial Chemicals: Applying trigger sprayers to cleaning products, insecticides, and automotive chemicals.
📜 Schedule virtual airflow visualization test.
💡 Mention your: Target market (EU/US/Global South), Active ingredient, Required throughput.
🔬 Schedule virtual factory acceptance test with our engineers.
🏷️ Request Compliance Audit: Free gap analysis with throughput simulation.
🔍Ready to Eliminate Production Bottlenecks?
💎Need Industrial Production Automation?
✅ GMP Compliance Guarantee
✅ 24/7 Multilingual Support
✅ 24-month performance guarantee
✅ Local technicians in 18 countries
📈Start small, get a free production layout designed for your growth trajectory. Scale smarter with engineering support!
📥Free line configuration for your products, throughput validation testing!
🎓Contact Specialists for Packaging Equipment:
📄 On-Demand Engineering: Product-specific configurations in 1-2 weeks.
🔧 Spare Parts Kits: Region-specific inventory for <24hr delivery.
🧼Compliance Roadmap:
- CE, EAC, ISO 9001 certifications.
- GMP-ready: 316L SS contact parts, CIP/SIP capabilities.
- ATEX options for chemical solvents.
