Description
The ACM-200 represents a significant leap in packaging automation for high-volume production environments. This linear capping machine is specifically designed with two independent capping heads that operate in parallel, allowing for the simultaneous sealing of two containers or a single container with two large closures.
The integrated dual-stream orienter is key to its performance, automatically sorting, aligning, and feeding caps through two separate channels to keep pace with the high-speed capping heads. This design minimizes bottlenecks and ensures a continuous, smooth production flow. Each capping head provides precise, adjustable torque control, guaranteeing a consistent and secure, leak-proof seal on every single cap, which is critical for product safety and shelf life. Built for durability and easy maintenance, the ACM-200 is constructed to withstand demanding industrial use.
Key Features and Benefits
-
Twin-Head Simultaneous Capping: Two independent capping heads double productivity by applying caps to two containers at once, perfectly suited for large caps.
-
Dual-Stream Cap Orienter: Features two separate sorting and feeding tracks to ensure a continuous, high-volume supply of correctly aligned caps, preventing jams and maximizing line efficiency.
-
Precise Torque Control: Each head applies consistent, adjustable force to ensure a uniform, leak-proof seal without damaging caps or containers.
-
Robust Linear Design: The linear configuration allows for straightforward integration into existing conveyor systems, providing reliable and continuous operation.
-
High-Speed Automation: Engineered for continuous, high-throughput production, significantly increasing packaging line output and reducing labor costs.
📊 Technical Specifications & Applications
| Specification | Details |
|---|---|
| Machine Model | ACM-200 Automatic Linear Capping Machine |
| Number of Capping Heads | 2 |
| Cap Feeding System | Dual-Stream Orienter |
| Application Speed | Up to 10-25 containers per minute |
| Cap Types | Large Caps (48mm-120mm diameter) |
| Power Supply | 220V, 50 Hz, 1-Phase |
| Machine Dimensions | 2.800 x 850 x 1.900 mm |
| Weight | Approximately 800 kg |
Industries and Applications
The ACM-200 is perfectly suited for:
-
Chemicals & Household Products: Sealing large containers for detergents, lubricants, and automotive chemicals.
-
Food & Beverage: Capping large jars, bottles, and pouches for sauces, oils, and other food products.
-
Pharmaceuticals & Cosmetics: Applying large lids to containers for powders, creams, and lotions.
📜 Schedule virtual airflow visualization test.
💡 Mention your: Target market (EU/US/Global South), Active ingredient, Required throughput.
🔬 Schedule virtual factory acceptance test with our engineers.
🏷️ Request Compliance Audit: Free gap analysis with throughput simulation.
🔍Ready to Eliminate Production Bottlenecks?
💎Need Industrial Production Automation?
✅ GMP Compliance Guarantee
✅ 24/7 Multilingual Support
✅ 24-month performance guarantee
✅ Local technicians in 18 countries
📈Start small, get a free production layout designed for your growth trajectory. Scale smarter with engineering support!
📥Free line configuration for your products, throughput validation testing!
🎓Contact Specialists for Packaging Equipment:
📄 On-Demand Engineering: Product-specific configurations in 1-2 weeks.
🔧 Spare Parts Kits: Region-specific inventory for <24hr delivery.
🧼Compliance Roadmap:
- CE, EAC, ISO 9001 certifications.
- GMP-ready: 316L SS contact parts, CIP/SIP capabilities.
- ATEX options for chemical solvents.
