Description
Precision Engineering for Complex Formulations and Quality Control
This 800L reactor is a versatile system designed for processes where consistent product quality and strict environmental control are paramount. The integrated sampling mechanism is a critical feature, allowing operators to monitor reaction progress, check composition, and ensure quality without stopping the process or risking contamination .
Core System Components & Advantages
-
Built-in Sampling Device: The reactor includes a sterilizable sampling valve or port that enables the withdrawal of representative product samples directly from the reaction vessel. This allows for real-time quality control and is essential for meeting stringent regulatory standards in industries like pharmaceuticals .
-
Efficient Mixing System: Equipped with a powerful agitator (options may include anchor, impeller, or turbine types), the reactor ensures perfect homogeneity, efficient heat transfer, and consistent product quality, even for medium to high-viscosity materials .
-
Hygienic GMP Design: The reactor is constructed with hygiene and compliance in mind. All product contact surfaces are made of polished stainless steel (e.g., AISI 316L), with a high-quality surface finish (e.g., Ra ≤ 0.8 µm) to prevent material adhesion and facilitate easy cleaning and sterilization .
-
Full Control and Monitoring: The system can be equipped with an advanced PLC and HMI (Human-Machine Interface) for precise control over all process parameters, including agitator speed, temperature, and pressure. Integration of various sensors (temperature, pressure, pH) allows for comprehensive process monitoring .
Built for Compliance and Global Market Excellence
The reactor’s design, including its sealed nature, cleanable surfaces, and sampling integrity, supports adherence to international regulatory standards like GMP. This is crucial for exporting your pharmaceutical substances and cosmetic products to markets in Southeast Asia, Africa, the Middle East, and Latin America .
Technical Specifications (To be filled from your data)
| Technical Parameter | V-50 |
|---|---|
| Total Reactor Volume | 800L |
| Agitator Type & Power | Anchor agitator, XX kW motor, 0-XXX RPM (variable speed) |
| Sampling Device Type | Sterilizable sampling valve, closed-loop sampling system |
| Heating/Cooling System | Jacket type (e.g., dimpled), temperature range, media |
| Operating Pressure | Full vacuum to +X bar |
| Materials of Construction | Vessel: 316L SS, Seals: EPDM/PTFE, Surface Finish: Ra < 0.8 µm |
| Control System | PLC with HMI touchscreen, data logging |
📜 Schedule virtual airflow visualization test.
💡 Mention your: Target market (EU/US/Global South), Active ingredient, Required throughput.
🔬 Schedule virtual factory acceptance test with our engineers.
🏷️ Request Compliance Audit: Free gap analysis with throughput simulation.
🔍Ready to Eliminate Production Bottlenecks?
💎Need Industrial Production Automation?
✅ GMP Compliance Guarantee
✅ 24/7 Multilingual Support
✅ 24-month performance guarantee
✅ Local technicians in 18 countries
📈Start small, get a free production layout designed for your growth trajectory. Scale smarter with engineering support!
📥Free line configuration for your products, throughput validation testing!
🎓Contact Specialists for Packaging Equipment:
📄 On-Demand Engineering: Product-specific configurations in 1-2 weeks.
🔧 Spare Parts Kits: Region-specific inventory for <24hr delivery.
🧼Compliance Roadmap:
- CE, EAC, ISO 9001 certifications.
- GMP-ready: 316L SS contact parts, CIP/SIP capabilities.
- ATEX options for chemical solvents.
