Description
Versatile and Efficient Processing for Demanding Applications
The 100L Mobile Multifunctional Reactor is built to handle everything from simple mixing to complex chemical reactions. Its overpressure capability allows for processes that require a controlled atmosphere or higher temperatures. The integrated mobility enables easy movement between processing, cleaning, and storage areas, significantly enhancing operational workflow and flexibility .
Key Features and Operational Advantages
-
Multifunctional Agitation System: Equipped with a powerful and variable-speed agitator, capable of handling a wide range of viscosities, from thin solutions to thick pastes and creams, ensuring perfect homogeneity .
-
Hygienic and Compliant Design: Constructed with high-quality Stainless Steel (AISI 304 or 316L) and featuring a high-grade surface finish (e.g., mirror polish with Ra ≤ 0.4 µm). This design supports easy cleaning, prevents contamination, and complies with GMP and food safety standards .
-
Temperature Control Jacket: The reactor includes a jacketed vessel for precise heating or cooling using thermal fluids (e.g., steam, water, or thermal oil). This is critical for controlling reaction kinetics and product quality in processes like emulsion preparation or ingredient synthesis .
-
Robust Mobile Platform: Mounted on a frame with lockable castors, providing stability during operation and ease of relocation without the need for fixed installation .
Built for Compliance and Global Market Excellence
The reactor’s design supports adherence to international regulatory standards.
Technical Specifications
| Parameter | Specification |
|---|---|
| Total Volume | 100 L |
| Working Volume | ~70-80 L |
| Design Pressure (Internal/Jacket) | -1 to +6 bar |
| Design Temperature Range | -10°C to +200°C |
| Agitator Type & Power | Anchor/Turbine, 0.75 kW |
| Material of Construction | Stainless Steel AISI 304/316L |
| Surface Finish | Mirror Polish, Ra ≤ 0.4 µm |
📜 Schedule virtual airflow visualization test.
💡 Mention your: Target market (EU/US/Global South), Active ingredient, Required throughput.
🔬 Schedule virtual factory acceptance test with our engineers.
🏷️ Request Compliance Audit: Free gap analysis with throughput simulation.
🔍Ready to Eliminate Production Bottlenecks?
💎Need Industrial Production Automation?
✅ GMP Compliance Guarantee
✅ 24/7 Multilingual Support
✅ 24-month performance guarantee
✅ Local technicians in 18 countries
📈Start small, get a free production layout designed for your growth trajectory. Scale smarter with engineering support!
📥Free line configuration for your products, throughput validation testing!
🎓Contact Specialists for Packaging Equipment:
📄 On-Demand Engineering: Product-specific configurations in 1-2 weeks.
🔧 Spare Parts Kits: Region-specific inventory for <24hr delivery.
🧼Compliance Roadmap:
- CE, EAC, ISO 9001 certifications.
- GMP-ready: 316L SS contact parts, CIP/SIP capabilities.
- ATEX options for chemical solvents.
