Description
Precision Blending with Maximum Flexibility
The V-5 Compact Mobile V-Blender combines gentle gravity-based mixing with the convenience of portability. Its design is perfect for applications requiring high homogeneity without damaging fragile product structures, such as active pharmaceutical ingredients (APIs), cosmetic pigments, or food additives . The mobility allows for easy movement between processing, cleaning, and storage areas, enhancing workflow efficiency.
Key Technical Specifications & Operational Advantages
-
Efficient V-Shaped Mixing: The V-shaped drum creates a continuous splitting and recombining action of the product, leading to a perfectly homogeneous blend in a short time, typically between 6-10 minutes . The asymmetrical design prevents dead angles and material accumulation .
-
Compact and Mobile Design: Built with a small footprint and mounted on a mobile frame, the blender can be easily repositioned within a laboratory or production area as needed.
-
Hygienic GMP Design: All product contact parts are made from high-quality stainless steel (AISI 304 or 316L), with the interior mirror-polished for easy cleaning, no contamination, and compliance with GMP standards .
-
Gentle Processing: The gravity-based mixing principle is non-destructive, preserving the structure of granules and fragile components .
-
User-Friendly Operation: Features simple controls and can be equipped with optional timers for automated operation .
Built for Compliance and Global Market Excellence
The blender’s design, focused on cleanability and the use of compliant materials, supports adherence to international regulatory standards. This is crucial for exporting your products to markets in Southeast Asia, Africa, the Middle East, and Latin America.
Technical Specifications
| Parameter | Specification |
|---|---|
| Total Drum Volume | 5 L |
| Working Capacity | ~2 L (approx. 40% of total volume) |
| Mixing Time | 6-10 minutes |
| Rotation Speed | ~60 rpm |
| Motor Power | 0.25 — 0.37 kW |
| Material of Construction | Stainless Steel AISI 304 / 316L |
| Technical Parameter | V-5 |
|---|---|
| Motor Power (kW) and Rotation Speed (RPM) | Check the motor nameplate or product manual. |
| Material Grade (e.g., AISI 304, 316L) | Check material certificates or product specs. |
| Dimensions and Weight | Directly measure the machine or refer to design drawings. |
| Power Requirements (Voltage, Phase) | Check the machine’s power label or manual. |
| Optional Features (e.g., timer, frequency converter) | Review the full product specification sheet. |
📜 Schedule virtual airflow visualization test.
💡 Mention your: Target market (EU/US/Global South), Active ingredient, Required throughput.
🔬 Schedule virtual factory acceptance test with our engineers.
🏷️ Request Compliance Audit: Free gap analysis with throughput simulation.
🔍Ready to Eliminate Production Bottlenecks?
💎Need Industrial Production Automation?
✅ GMP Compliance Guarantee
✅ 24/7 Multilingual Support
✅ 24-month performance guarantee
✅ Local technicians in 18 countries
📈Start small, get a free production layout designed for your growth trajectory. Scale smarter with engineering support!
📥Free line configuration for your products, throughput validation testing!
🎓Contact Specialists for Packaging Equipment:
📄 On-Demand Engineering: Product-specific configurations in 1-2 weeks.
🔧 Spare Parts Kits: Region-specific inventory for <24hr delivery.
🧼Compliance Roadmap:
- CE, EAC, ISO 9001 certifications.
- GMP-ready: 316L SS contact parts, CIP/SIP capabilities.
- ATEX options for chemical solvents.
