Description

Precision 360° Labeling Solution for Polygonal and Multi-Faceted Containers

The Universal Semi-Automatic Bench-Top Labeling Machine L-20 (Wrap-Around Version) masters one of the most complex labeling challenges: applying a contiguous label around containers with flat surfaces and sharp angles. It transforms intricate manual work into a repeatable, automated process, delivering flawless results that elevate premium product presentation.

How It Works & Key Features:

The operator places the bottle horizontally into a dedicated holder. Activating the machine triggers a clamp to secure the container by its cap, after which the bottle begins to rotate. Simultaneously, the label is dispensed and smoothly wrapped around the entire surface by a soft pressure roller mounted on a pneumatic cylinder, ensuring complete adhesion without wrinkles or misalignment on edges.

• Specialized for Polygonal Shapes: Uniquely engineered for square, rectangular, diamond-shaped, conical, and other multi-faceted containers that standard labelers cannot handle with a full-wrap label.

• Horizontal Rotation & Wrapping Mechanism: The core innovation. The container rotates horizontally while a pneumatic soft roller applies the label, enabling precise 360° wrap-around application on flat surfaces and corners.

• Versatile Labeling Modes: Can apply a single label, two sequentially placed labels (front & back), or a label on a specific corner, offering exceptional flexibility for various designs.

• Gentle yet Secure Handling: Features a soft pressure roller and secure clamping from the cap side to protect delicate or premium containers from damage during labeling.

• GMP-Ready & Precise: Built for high-quality production environments, with a design that ensures repeatable accuracy and options for 316L stainless steel contact parts.

Ideal Applications & Integration:

This machine is indispensable for brands that use distinctive, angular bottles for high-end cosmetics (serums, perfumes), spirits (whisky, vodka bottles), specialty foods (gourmet oils, vinegar), and pharmaceutical products. It integrates into a premium packaging line and can be combined with other semi-automatic equipment like fillers and cappers.
