TBM-20 Semi-Automatic Tube Filling and Crimping Machine

Precision and Reliability for Demanding Applications
The TBM-20 semi-automatic monoblock streamlines your packaging process by integrating filling and crimping operations into a single, efficient workstation. Designed for operator-friendly performance, this machine delivers consistent, high-quality results for a diverse array of viscous products, ensuring your brand’s integrity and shelf life. Its robust construction and advanced features make it a trusted choice for manufacturers globally.

Key Features:

• ✅ Integrated Process: Combines filling and crimping in one compact unit.

• ✅ High Accuracy: Piston filler system ensures precise dosing with minimal product waste.

• ✅ Secure Sealing: Robust crimping module creates a hermetic, tamper-evident seal.

• ✅ Date & Batch Coding: Integrated embossing unit marks each tube with production data.

• ✅ Hygienic Design: Easy-to-clean SS304/316 construction, compliant with GMP standards.

Engineered for Your Industry and Products
This versatile monobloc is the perfect packaging solution for multiple sectors:

• Pharmaceutical & Veterinary: Medicated ointments, topical creams, gels, and veterinary products.

• Cosmetics & Personal Care: Facial creams, hair gels, toothpaste, and lotions.

• Chemical & Industrial: Adhesives, sealants, lubricants, dyes, paints, and specialty chemicals.

Whether you’re packaging a sensitive pharmaceutical cream or a high-viscosity industrial adhesive, the TBM-20 handles it with precision and reliability.

Advanced Features for Enhanced Performance

• Rotary Indexing Table: Ensures smooth and precise positioning of tubes for each operation cycle.

• Photoelectric Sensor: Guarantees accurate tube placement and activation, preventing errors and waste.

• Piston Filler System: Provides exceptional volumetric accuracy (±0.5%) for both thick and thin products, eliminating giveaway.

• Automatic Crimping Jaw: Creates a consistent, secure, and leak-proof double-seam crimp on aluminum tubes.

• Embossing Unit: Equipped with rotary type dies to permanently mark each tube’s crimp with crucial batch numbers and expiration dates for full traceability.

• Stainless Steel Construction: All product-contact parts are made from corrosion-resistant SS304 or SS316, meeting hygiene standards for easy cleaning and maintenance.

Technical Specifications

Why Choose the TBM-20 Monoblock?

• Cost-Effective Automation: Perfect entry-level solution for companies automating their tube packaging without the cost of a full automatic line.

• Easy to Use & Maintain: Simple controls and robust design minimize training and downtime.

• Quick Changeover: Adaptable to different tube diameters and lengths with change parts.

• Global Compliance: Built to perform reliably in diverse operating environments across Southeast Asia, the Middle East, Africa, and Latin America.

• Durable Investment: Engineered for long-term performance in demanding production settings.
