TBM-20 Semi-Automatic Tube Filling and Crimping Machine
Key Features:
-
✅ Integrated Process: Combines filling and crimping in one unit.
-
✅ High Accuracy: Piston filler minimizes product waste.
-
✅ Secure Sealing: Double-seam crimp prevents leaks.
-
✅ Date/Batch Coding: Embossing unit marks tubes for traceability.
-
✅ Hygienic Design: Easy-to-clean SS304/316 construction.
Precision Filling and Sealing for Diverse Industries
The TBM-20 semi-automatic monobloc streamlines tube packaging by integrating filling and crimping into a single, efficient workstation. Designed for operator-friendly performance, it delivers consistent results for viscous products like ointments, creams, gels, pastes, and chemicals. Its versatility makes it suitable for:
-
Pharmaceuticals & Veterinary: Medicated ointments, topical creams.
-
Cosmetics & Personal Care: Toothpaste, facial creams, hair gels.
-
Food Industry: Condiments, food pastes.
-
Chemicals: Adhesives, lubricants, sealants .
Advanced Features for Reliable Performance
-
Rotary Indexing Table: Ensures smooth tube positioning.
-
Photoelectric Sensor: Guarantees accurate tube placement, reducing errors.
-
Piston Filler System: Provides volumetric accuracy (±0.5%) for products of varying viscosities.
-
Automatic Crimping Jaw: Creates a hermetic, tamper-evident seal.
-
Embossing Unit: Marks each tube’s crimp with batch numbers and expiration dates for full traceability.
-
Durable Construction: SS304/316 stainless steel contact parts resist corrosion and enable easy cleaning .
Technical Specifications
| Parameter | Specification |
|---|---|
| Machine Type | Semi-Automatic Monobloc (Filling + Crimping) |
| Max Speed | Up to 20 tubes/minute |
| Filling Accuracy | ±0.5% |
| Filling Volume Range | 5 ml — 500 ml (adjustable) |
| Crimping Method | Double-seam crimp |
| Coding | Embossing for batch/date on tube seam |
| Power Supply | 110V / 220V, 50/60 Hz |
| Pneumatic Pressure | 0.6 — 0.8 MPa (6-8 bar) |
| Construction Materials | SS304/316 (contact parts), powder-coated frame |
Why Choose the TBM-20?
-
Cost-Effective Automation: Ideal for small-to-medium batch production and R&D.
-
Easy Operation: Minimal training required; foot-pedal controlled.
-
Quick Changeover: Adaptable to various tube diameters with change parts.
-
Global Compliance: Built for reliability in diverse climates (e.g., humidity, dust).
-
Reduced Waste: Precision filling minimizes product giveaway .
📜 Schedule virtual airflow visualization test.
💡 Mention your: Target market (EU/US/Global South), Active ingredient, Required throughput.
🔬 Schedule virtual factory acceptance test with our engineers.
🏷️ Request Compliance Audit: Free gap analysis with throughput simulation.
🔍Ready to Eliminate Production Bottlenecks?
💎Need Industrial Production Automation?
✅ GMP Compliance Guarantee
✅ 24/7 Multilingual Support
✅ 24-month performance guarantee
✅ Local technicians in 18 countries
📈Start small, get a free production layout designed for your growth trajectory. Scale smarter with engineering support!
📥Free line configuration for your products, throughput validation testing!
🎓Contact Specialists for Packaging Equipment:
📄 On-Demand Engineering: Product-specific configurations in 1-2 weeks.
🔧 Spare Parts Kits: Region-specific inventory for <24hr delivery.
🧼Compliance Roadmap:
- CE, EAC, ISO 9001 certifications.
- GMP-ready: 316L SS contact parts, CIP/SIP capabilities.
- ATEX options for chemical solvents.
