Description

Semi-Automatic Rotary Monoblock for High-Viscosity Chemical Packaging

Semi-automatic rotary cartridge filling monoblock.

High-pressure hose connection system.

Automatic cartridge orientation and capping.

This semi-automatic rotary-type monoblock is specifically designed for packaging high-viscosity products into construction cartridges. The system features a high-pressure hose connection to hydraulic presses, automatic cartridge and cap orientation systems, and precision capping station. Ideal for sealants, technical lubricants, adhesives, and other construction chemicals, this machine handles products with viscosities up to 500,000 cP while maintaining production rates of 20+ cartridges per minute.

Key Features:

• ✅ Hydraulic Press System: Ensures consistent flow of high-viscosity products from containers like pails or drums.

• ✅ High-Pressure Hose: Facilitates efficient product transfer without clogging.

• ✅ Rotary Indexing Table: Enables continuous operation with multiple stations for filling and capping.

• ✅ Precision Dispensing: Piston-driven system provides ±1% filling accuracy.

• ✅ Automatic Capping: Vibratory cap orienter and capping heads ensure secure, leak-proof seals.

• ✅ Hygienic Design: SS304/316 stainless steel contact parts, easy to clean and maintain.

Efficient Packaging Solution for High-Viscosity Sealants
The TBC-20 semi-automatic rotary monoblock combines a hydraulic press, high-pressure hose, and rotary indexing table to streamline the packaging of high-viscosity sealants into plastic tubes. Designed for construction chemicals, industrial sealants, and adhesives, this machine ensures consistent results with minimal operator intervention. Its robust construction and advanced features make it an ideal choice for manufacturers seeking to enhance their packaging processes in regions like Southeast Asia, Africa, and Latin America, where reliability and efficiency are critical .

Advanced Features for Enhanced Performance

• Hydraulic Press System: Applies controlled pressure to extract high-viscosity products from containers, ensuring consistent flow and minimizing waste. The press can be equipped with vacuum lids to improve product quality .

• High-Pressure Hose: Designed to handle products with viscosities up to 500,000 cP, preventing clogging and ensuring smooth operation.

• Rotary Indexing Table: Allows simultaneous operations (filling, capping) for high throughput, reducing cycle times and increasing productivity.

• Piston Dispensing Technology: Provides precise volumetric control with ±1% accuracy, minimizing product giveaway and ensuring consistency.

• Automatic Capping Mechanism: Features a vibratory cap orienter and capping heads that apply secure, leak-proof seals with consistent torque.

• Robust Construction: SS304/316 stainless steel contact parts resist corrosion and meet industry hygiene standards, ensuring long-term reliability .

Key Features:

• Rotary indexing table design

• High-pressure hose connection to hydraulic press

• Automatic cartridge orientation system

• Cap feeding and orientation system

• Precision capping station

• Handles viscosities up to 500,000 cP

• SS304/316 stainless steel construction

• 20+ cartridges per minute capacity

Technical Specifications:

Advanced Rotary System for Construction Chemical Packaging
This semi-automatic rotary monoblock provides efficient packaging solution for high-viscosity construction products. The rotary design enables continuous operation with multiple stations handling orientation, filling, and capping simultaneously.

Technical Specifications Table:

Key Benefits:

• Continuous Operation: Rotary design enables simultaneous processing

• High-Pressure Capability: Handles most viscous materials effectively

• Automatic Orientation: Reduces manual handling and increases efficiency

• Precision Capping: Ensures secure, leak-proof seals

• Versatile Application: Suitable for various construction chemicals

• Easy Maintenance: Quick-disconnect components for cleaning

• Space-Efficient: Compact design for limited production areas

Applications:

• Construction sealant packaging

• Industrial lubricant filling

• Adhesive and compound packaging

• Technical chemical applications

• Building material packaging

Industries Served:

• Construction chemicals manufacturing

• Industrial lubricant production

• Adhesive and sealant manufacturing

• Building materials industry

• Chemical processing

Applications & Industries

• Construction Chemicals: Sealants, adhesives, caulks, and mortars.

• Industrial Lubricants: Greases, lubricating compounds, and technical gels.

• Automotive Products: Anti-seize compounds, brake lubricants, and assembly pastes.

• General Industrial Use: Specialty chemicals, maintenance products, and waterproofing materials .

Why Choose the TBC-20 Semi-Automatic Rotary Monoblock?

• High Efficiency: Rotary design and hydraulic press enable continuous operation, reducing downtime and maximizing output.

• Precision and Consistency: Ensures accurate fills and secure seals, reducing waste and enhancing product quality.

• Versatility: Suitable for a wide range of high-viscosity products and tube sizes.

• Durability: Built to withstand harsh industrial environments with minimal maintenance.

• Global Compliance: Designed to meet international safety and hygiene standards for export markets

Construction chemical packaging system.

TBC-20 Semi-Automatic Rotary Monoblock for Sealant Packaging.
