Automate the Feeding of Flat Items to Your Packaging Line
How the LLF-100 Streamlines Your Production Process.
Ideal for a Wide Range of Packaging & Printing Applications.
Manual feeding of bags, envelopes, and packs is slow, inconsistent, and prone to errors. The LLF-100 solves this by providing a dedicated, mechanical station that automatically separates the top item from a stack and places it precisely onto a conveyor. This ensures a steady, singularized flow of materials to your labeling, inkjet printing, or quality control station, dramatically improving line speed and reliability.
How the LLF-100 Streamlines Your Production Process
The LLF-100 uses a proven friction-based or vacuum-assisted feeding mechanism:
-
Operator-Loaded Stack: An operator places a stack of flat items (bags, packs, etc.) into the machine’s magazine.
-
Automatic Separation: The machine’s feeding mechanism (friction rollers or suction cups) reliably separates the top item from the stack.
-
Precise Transfer: The separated item is then conveyed or dropped onto the integrated or downstream conveyor belt, positioned for the next operation.
-
Semi-Automatic Cycle: The cycle is typically initiated by the operator or triggered by a sensor from the downstream machine, providing flexible integration.
Technical Specifications & Performance Data
| Parameter | Specification |
|---|---|
| Machine Type | Semi-Automatic, Floor-Standing Flat Item Feeder (Paginator) |
| Primary Function | Separation & feeding of flat items from a stack |
| Typical Materials | Plastic bags, paper envelopes, folded cartons, product packs, labels, cards |
| Feeding Mechanism | Friction roller or vacuum suction cup system |
| Control | Simple push-button or sensor-activated cycle |
| Construction | Robust steel frame, stainless steel contact surfaces available |
| Power Supply | Customizable (110V, 220V, 380V, 480V) |
| Footprint | Designed for floor placement, approximate dimensions: 1500L x 800W x 1200H mm |
| Integration | Output conveyor integrates with labeling, printing, or inspection stations |
Ideal for a Wide Range of Packaging & Printing Applications
-
Industries: Pharmaceuticals & Nutraceuticals, Cosmetics & Personal Care, Food & Confectionery, Printing & Mailing, General Manufacturing.
-
Materials: Flat plastic pouches, paper bags, folded cardboard packs (e.g., for medicine blisters), envelopes, instruction leaflets, promotional cards.
-
Downstream Processes: Automatic label application, inkjet coding (date/batch/serial number), barcode verification, quality inspection cameras.
Durable Construction & Global Compliance Support
Built for reliability in industrial environments and supported worldwide:
-
Robust Design: Constructed with a heavy-duty steel frame for stability and long service life.
-
Hygienic Options: Available with 304/316L stainless steel contact parts for easy cleaning and GMP-ready applications.
-
Global Support: Backed by 24/7 multilingual support (EN/RU/AR/ES) and regional technical hubs in Dubai (MENA), Hanoi (SE Asia), and Lagos (Africa) for rapid service.
-
Customization: Voltage is customized for your region, and machine adjustments can be made for different item sizes.
Your Partner for Enhanced Line Efficiency
Integrating the LLF-100 is a cost-effective step towards automation. We offer free line integration analysis to ensure this feeder seamlessly connects with your existing equipment. Backed by a 24-month performance guarantee and our global engineering support, the LLF-100 is designed to boost your productivity from day one.
