Description

Simultaneous Front & Back Labeling for Large Flat and Elliptical Containers

Dual-Sided Application System with Advanced Label Smoothing.

Built for Demanding Industries: Pharma, Chemicals, Food & Cosmetics.

The LL-200 addresses a critical need in industrial packaging: the efficient and accurate application of primary and secondary labels on opposite sides of large, often non-cylindrical containers. This system eliminates the need for two separate labeling passes, doubling productivity and ensuring perfect label alignment for compliance and branding on items like 5-gallon pails, elliptical chemical cans with handles, and large rectangular bottles.

Dual-Sided Application System with Advanced Label Smoothing

This line is built around precision and adaptability:

• Dual LOCUS LABEL Applicators: Left and right side-mount applicators work in sync to apply front and back labels simultaneously as the container passes through.

• Container Orientation & Stabilization: Equipped with container orienters (side guide rollers) and an optional top pressure conveyor to secure tall or unstable containers during labeling.

• Advanced Smoothing Mechanism: Features side pressure brushes or driven foam polyurethane rollers that actively smooth labels onto both flat and convex (elliptical) surfaces, ensuring bubble-free adhesion.

• Precision Sensing: Can be fitted with optical or ultrasonic sensors, the latter being ideal for clear or metallized labels.

Technical Specifications & Configurable Setup

Built for Demanding Industries: Pharma, Chemicals, Food & Cosmetics

• Chemicals & Automotive: Labeling large HDPE cans of motor oil, solvents, cleaning agents, agrochemicals. Perfect for containers with handles.

• Pharmaceuticals: Applying dual-side labels on large bottles of bulk ingredients, sanitizers, or clinical solutions.

• Food & Beverage: Labeling large containers of cooking oils, syrups, or industrial food ingredients.

• Cosmetics: Labeling bulk containers of raw materials or finished products.

Simple Operation with Advanced Integration Potential

Operation is streamlined for efficiency:

1. Loading: Operator places containers (empty or filled) onto the conveyor.

2. Transport & Sensing: Containers move past the sensor, which triggers both applicators.

3. Application & Smoothing: Labels are applied to both sides and immediately smoothed by the rollers/brushes.

4. Discharge/Integration: Labeled containers exit. An optional indexing disc ensures proper spacing. The line can feed directly into accumulation tables or integrate with upstream/downstream packaging machinery.

A Versatile Solution for Diverse Container Geometries

The LL-200’s true strength is its flexibility. It is not just a machine but a configurable system that can be adapted for small vials, large-diameter jars, tall containers, or specialized elliptical cans. This makes it a future-proof investment for growing product portfolios. Its mobile design on casters allows it to serve multiple production lines or be easily repositioned within the facility.

Simple Operation with Advanced Integration Potential.

A Versatile Solution for Diverse Container Geometries.
