TBC-10 Compact Semi-Automatic Monoblock for Filling Sealants and Lubricants into Construction Cartridges

TBC-10 Compact Monoblock for Filling Sealants and Lubricants into Construction Cartridges.

Pressure-fed dispensing system for viscous materials.

Vibratory cap orientation and capping system.

This semi-automatic workstation is designed for packaging viscous construction products into standard cartridges. The system features a pressure-fed single nozzle dispenser, vibratory cap orienter, and automatic capping station. Ideal for sealants, technical lubricants (lithol, solidol), PVA construction adhesives, and other building chemicals, this machine handles products supplied under pressure from pipelines or hydraulic systems. With production capacity of 15-20 cartridges per minute and robust SS304/316 construction, it ensures reliable performance in industrial environments.

Key Features:

• ✅ Dual Nozzle Dispensing: Doubles productivity with simultaneous filling of two cartridges.

• ✅ Automatic Cap Orientation: Vibratory bowl system ensures precise cap positioning.

• ✅ Secure Capping Mechanism: Provides leak-proof seals with consistent torque control.

• ✅ High-Viscosity Handling: Efficiently processes products up to 500,000 cP.

• ✅ Compact Design: Space-saving footprint ideal for limited production areas.

• ✅ Hygienic Construction: SS304/316 stainless steel contact parts, compliant with industrial standards.

Efficient and Compact Packaging for Construction Chemicals
The TBC-10 compact monoblock is engineered to streamline the packaging of sealants, lubricants, and other viscous industrial chemicals into construction cartridges. Its dual-nozzle design significantly enhances productivity by allowing simultaneous filling of two cartridges, while the integrated cap orientation and capping systems ensure a complete packaging solution. This machine is particularly suited for manufacturers targeting the construction, automotive, and industrial sectors, offering reliability and precision in a compact, user-friendly format.

Advanced Features for Enhanced Performance

• Dual Nozzle Dispensing System: Two independent dispensing units enable high-speed filling with ±1% accuracy, reducing cycle times and increasing output.

• Automatic Cap Orientation: A vibratory bowl feeder ensures caps are correctly positioned and fed to the capping station, minimizing errors and manual intervention.

• Secure Capping Mechanism: Applies consistent torque for leak-proof seals, critical for maintaining product integrity during storage and transport.

• High-Viscosity Compatibility: Handles thick products like sealants, greases (e.g., lithol, solidol), and adhesives without clogging, thanks to its robust hydraulic or piston-driven dispensing system.

• Compact and Mobile Design: Its small footprint makes it ideal for facilities with space constraints, while stainless steel construction ensures longevity and easy cleaning.

• User-Friendly Controls: Semi-automatic operation with intuitive controls reduces training time and allows for quick changeovers between products.

Key Features:

• Pressure-fed dispensing system for viscous materials

• Vibratory cap orientation and feeding system

• Automatic capping station with torque control

• Handles products from pipelines or hydraulic presses

• SS304/316 stainless steel construction

• Semi-automatic operation with easy controls

• Suitable for products up to 500,000 cP viscosity

• Compact footprint for limited space

Technical Specifications:

Precision Packaging for Construction Chemicals
This semi-automatic system provides reliable packaging solution for viscous construction materials. The pressure-fed design ensures consistent product flow even with high-viscosity materials, while the automatic capping system guarantees secure, leak-proof seals.

Technical Specifications Table:

Key Benefits:

• Consistent Performance: Pressure-fed system ensures reliable product flow

• Precision Capping: Automatic cap orientation and secure sealing

• Versatile Application: Handles various construction chemicals and lubricants

• Easy Operation: Semi-automatic design requires minimal training

• Durable Construction: Stainless steel components withstand harsh environments

• Quick Changeover: Easy adaptation to different products and container sizes

Industries Served:

• Construction chemicals manufacturing

• Industrial lubricant production

• Sealant and adhesive manufacturing

• Building materials packaging

• Technical chemical products

Applications & Industries

• Construction Chemicals: Sealants, adhesives, caulks, and mortars.

• Industrial Lubricants: Greases, lubricating compounds (e.g., lithol, solidol), and technical gels.

• Automotive Products: Anti-seize compounds, brake lubricants, and assembly pastes.

• General Industrial Use: Specialty chemicals, maintenance products, and waterproofing materials.

Why Choose the TBC-10 Compact Monoblock?

• Increased Productivity: Dual-nozzle design doubles output compared to single-nozzle systems, ideal for medium-scale production.

• Precision and Reliability: Ensures accurate fills and secure seals, reducing waste and enhancing product quality.

• Versatility: Suitable for a wide range of high-viscosity products and cartridge sizes.

• Durability: Built with corrosion-resistant materials for long-term use in harsh environments.

• Ease of Integration: Compact size and semi-automatic operation make it easy to incorporate into existing production lines.

TBC-10 Compact Cartridge Filling Monoblock.

Construction chemical packaging workstation.

TBC-10 Compact Semi-Automatic Cartridge Filling Monoblock.

Semi-automatic cartridge filling machine for construction chemicals.
