TBC-10 Semi-Automatic Cartridge Dispenser
Efficient Packaging Solution for High-Viscosity Products
The TBC-10 semi-automatic cartridge dispenser combines precision filling and capping into a single, efficient system. Designed for sealants, lubricants, adhesives, and industrial chemicals, this machine ensures consistent results with minimal operator intervention. Its robust construction and advanced features make it an ideal choice for manufacturers in the construction, automotive, and chemical industries seeking to enhance their packaging processes.
Key Features:
-
✅ Automatic Cartridge Orienter: Ensures correct positioning of cartridges for error-free operation.
-
✅ Precision Dispensing: Piston-driven system provides ±1% filling accuracy.
-
✅ Automatic Capping: Vibratory cap orienter and capping heads ensure secure, leak-proof seals.
-
✅ High-Viscosity Handling: Capable of processing products up to 500,000 cP.
-
✅ Hygienic Design: SS304/316 stainless steel contact parts, easy to clean and maintain.
-
✅ User-Friendly Operation: Semi-automatic design reduces training time and costs.
Advanced Features for Enhanced Performance
-
Automatic Cartridge Orienter: Ensures cartridges are correctly positioned before filling, reducing errors and maximizing efficiency.
-
Piston Dispensing System: Provides precise volumetric control with ±1% accuracy, minimizing product waste and ensuring consistency.
-
Automatic Capping Mechanism: Features a vibratory cap orienter and capping heads that apply secure, leak-proof seals with consistent torque.
-
High-Viscosity Compatibility: Handles products with viscosities up to 500,000 cP, making it suitable for thick pastes, gels, and compounds.
-
Robust Construction: SS304/316 stainless steel contact parts resist corrosion and meet industry hygiene standards.
-
User-Friendly Controls: Semi-automatic operation with intuitive controls reduces training time and allows for quick changeovers.
Technical Specifications
| Parameter | Specification |
|---|---|
| Machine Type | Semi-Automatic Cartridge Dispenser with Orienter and Capper |
| Production Capacity | Up to 20 cartridges/minute |
| Filling Accuracy | ±1% |
| Filling Volume Range | 50 ml — 500 ml (adjustable) |
| Viscosity Range | Up to 500,000 cP |
| Power Supply | 220V/50Hz or 110V/60Hz |
| Construction Materials | SS304/316 stainless steel (contact parts) |
| Control System | PLC with touchscreen interface |
Applications & Industries
-
Construction Chemicals: Sealants, adhesives, caulks, and mortars.
-
Industrial Lubricants: Greases, lubricating compounds, and technical gels.
-
Automotive Products: Anti-seize compounds, brake lubricants, and assembly pastes.
-
General Industrial Use: Specialty chemicals, maintenance products, and waterproofing materials.
Why Choose the TBC-10 Semi-Automatic Dispenser?
-
Precision and Consistency: Ensures accurate fills and secure seals, reducing waste and enhancing product quality.
-
Versatility: Suitable for a wide range of high-viscosity products and cartridge sizes.
-
Ease of Use: Semi-automatic operation requires minimal training and operator intervention.
-
Durability: Built to withstand harsh industrial environments with minimal maintenance.
-
Global Compliance: Designed to meet international safety and hygiene standards.
