Semi-Automatic Bag-in-Box Dosator with Capper and Product Feed Pump: LFBB-100
Streamlined Packaging Operation in a Single Machine
The LFBB-100 Semi-Automatic Dosator is engineered for businesses seeking to enhance their packaging line’s efficiency without the complexity of a fully automated system. By integrating a product feed pump and a mechanical capper, this unit minimizes manual handling and accelerates the packaging process from filling to sealing. It is an ideal, cost-effective investment for manufacturers across Southeast Asia, Africa, the Middle East, and Latin America who require reliability and ease of operation.
Technical Specifications & Performance Data
| Specification Category | Details |
|---|---|
| Operation Type | Semi-Automatic |
| Filling Accuracy | ≤ ± 0.5% |
| Production Capacity | 150 — 200 bags/hour |
| Bag Volume Range | 1 — 25 liters |
| Power Supply | 220 V ± 10 %, 50 / 60 Hz |
| Air Pressure | 0.4 — 0.7 MPa |
| Control System | PLC |
| Product Contact Parts | Stainless Steel 304 |
Key Features & Operational Benefits
-
All-in-One Functionality: The combination of a pump for product transfer and a mechanism for securing caps simplifies the workflow, reducing the need for multiple pieces of equipment and saving valuable floor space .
-
Hygienic & Easy Maintenance: The use of food-grade stainless steel (AISI 304) on all product contact surfaces makes the machine easy to clean and compliant with international hygiene standards for food applications .
-
User-Friendly Control: A simple Programmable Logic Controller (PLC) allows for easy operation and quick changeovers between different products and bag sizes .
Industries & Application Solutions
-
Food & Beverage: Perfect for wine, fruit juice, edible oils, and liquid dairy products .
-
Chemical & Industrial: Suitable for packaging various non-hazardous liquid chemicals, soaps, and lubricants.
