Description
LSSC-50 Semi-Automatic Mobile Carton Sealer
LSSC-50 mobile sealer in warehouse aisle sealing box.
Dual taping heads applying tape to box bottom.
Locking caster wheels for repositioning.
Key Features
-
Mobility & Flexibility: Locking casters (150mm) for relocation; operates in aisles ≤1.5m wide.
-
Dual-Seam Sealing: Simultaneous top/bottom taping with 48-72mm pressure-sensitive tape (3M™-compatible).
-
Plug-and-Play: 220V single-phase power; 3-min setup with integrated tape dispensers.
-
All-Climate Ready: Seals reliably at -15°C to 40°C (critical for unheated warehouses).
Technical Specifications
| Parameter | Value |
|---|---|
| Throughput | 6-20 boxes/min |
| Box Dimensions | L: 200-500mm × W: 150-400mm × H: 100-350mm |
| Tape Rolls | 2 × 72mm cores (standard) |
| Power | 0.8 kW (220V) |
| Weight | 85 kg (portable via pallet jack) |
Industry Applications
-
Warehousing: Seal boxes directly at packing stations – no conveyor needed.
-
Agriculture: Mobile sealing for harvest-season produce boxes in fields/packing sheds.
-
E-commerce Startups: Cost-effective solution for <100 orders/day businesses.
-
Pharma Kits: Complies with GDP standards for clinical trial shipments.
Operation Workflow
-
Position Box: Operator places box on sealer platform.
-
Activate: Foot pedal lowers taping arms.
-
Seal: Tape applied to top/bottom seams simultaneously.
-
Remove: Sealed box manually transferred to pallet.
Tape reload: <60 sec | Zero training required
Competitive Advantages
| Feature | Benefit |
|---|---|
| No Infrastructure | Eliminates conveyors/power drops – runs on standard outlets |
| Tape Savings | Pre-cut tape segments reduce waste by 25% vs manual dispensers |
| Rugged Build | Powder-coated steel; IP54 rating for dusty/damp environments |
| Safety Focus | Emergency stop + finger-guarded tape heads |
Regional Adaptation
-
Africa/SEA: 50°C heat-resistant tapes; corrosion-proofed frame.
-
Eastern Europe: Operates in unheated warehouses (-15°C).
-
Latin America: 110V/60Hz version available; Spanish interface labels.
Compliance & Standards
-
Safety: CE, ISO 13849 (Category 1).
-
Tape: FDA 21 CFR 175.125 (indirect food contact).
-
Design: FEFCO 0201 compliant.
Technical Support
-
Global Kits: Pre-packed spare parts (belts, sensors, cutters)
-
Video Manuals: QR-code linked tutorials (EN/ES/FR)
-
Warranty: 3 years on frame, 1 year on electronics
