🍷 Professional Overview of RC-100 Wine Bottling Monoblock with Cork Stopper Insertion

The RC-100 Wine Bottling Monoblock is a robust, versatile solution for wineries seeking to automate their packaging process while preserving wine quality. Its isobaric filling technology, corking precision, and compliance with hygiene standards make it suitable for a range of wine types and production scales.

⚙️ 1. Technical Specifications and Design

• Capacity: The machine can handle up to 400 bottles per hour (for semi-automatic operations), with higher-capacity models (e.g., 1,500–12,000 bottles/hour) available for industrial-scale production3.

• Bottle Compatibility: Designed primarily for glass bottles (diameter: ø55–115 mm; height: up to 370 mm), but can be adapted for PET bottles and aluminum cans with specific accessories.

• Filling Technology: Uses isobaric (counter-pressure) filling to prevent oxidation and preserve wine quality. The system includes a tank with a working pressure of up to 5 bar and options for oxygen pre-evacuation.

• Corking System: Equipped with a turret for inserting cork stoppers (e.g., natural or synthetic corks) and can also handle crown caps for sparkling wines. The closing head is made of hardened steel for durability.

• Construction: Built from stainless steel and food-grade materials compliant with international regulations (e.g., EC 1935/2004 for food contact materials).

• Power Requirements: Typically operates on 220V 50Hz single-phase power (other voltages available on request), with low energy consumption (installed power: ~1.1 kW).

• Product Compatibility:

  • Spirits and liquors (vodka, whiskey, gin)

  • Wine-based products

  • Premium alcoholic beverages

  • Champagne and sparkling wines

• Bottle Types: Glass bottles and flacons of various sizes

• Closure Systems:

  • Natural cork stoppers

  • Plastic champagne stoppers

  • Mushroom-style closures

  • Technical corks

• Production Capacity: 2,000-4,000 bottles/hour

Technical Advantages:

• Premium Closure Handling: Specialized insertion systems for various closure types

• Gentle Product Processing: Maintains product integrity and quality

• Precision Filling: Accurate dosing for valuable alcoholic products

• Hygienic Design: CIP capability and sanitary construction

• Versatile Operation: Handles different bottle sizes and closure types

• Quality Presentation: Ensures premium packaging appearance

• Easy Changeover: Quick adjustment between products

Special Features:

• Carousel Rinsing: Efficient internal bottle cleaning

• Rotary Dosing System: Precise volumetric filling

• Cork Insertion: Gentle handling of natural corks

• Stopper Application: Secure placement of plastic stoppers

• Mushroom Stopper: Specialized closure capability

• Quality Control: Integrated inspection systems

• Hygiene System: Automated cleaning and sterilization

Applications:

• Distilleries: Premium spirits and liquors

• Wineries: Still and sparkling wines

• Champagne Houses: Sparkling wine production

• Liqueur Producers: Specialty alcoholic beverages

• Premium Brands: High-end alcoholic products

Quality Features:

• Product Protection: Maintains alcohol content and quality

• Secure Sealing: Ensures proper closure integrity

• Visual Appeal: Professional packaging presentation

• Contamination Prevention: Closed-system operation

• Process Control: Comprehensive monitoring systems

Operation Benefits:

• Premium Quality: Maintains product excellence

• Efficiency: High-speed operation for premium products

• Brand Enhancement: Ensures luxury presentation

• Cost Effectiveness: Reduces product waste

• Reliability: Consistent performance

• Compliance: Meets alcohol industry regulations

Technical Details:

• Power Requirements: 380V/50Hz/3Ph

• Control System: PLC with touchscreen interface

• Safety Features: Emergency stops, protective guarding

• Certifications: CE, FDA compliance

• Materials: Food-grade stainless steel

🔄 2. Key Features and Process

• Integrated Operations: Performs rinsing, filling, and corking in a single unit, reducing contamination risks and saving floor space.

• Rinsing Module: Uses water or sterile air to clean bottles before filling, ensuring hygiene3.

• Precision Filling: The isobaric system minimizes oxygen exposure by injecting CO₂ to create a neutral atmosphere, crucial for preserving wine aroma and taste.

• Cork Insertion: Includes an automatic cork orienter and feeder (e.g., vibration hopper) to ensure consistent cork placement. For sparkling wines, it can handle crown caps and optional bidule insertion for traditional method wines.

• Hygiene and Maintenance: Designed for easy cleaning with CIP (Clean-in-Place) capabilities and accessible components.

• Advanced Controls: Features a PLC with touchscreen interface for adjusting parameters (e.g., filling volume, corking pressure) and storing recipes. Optional remote monitoring for Industry 4.0 integration.

🍾 3. Applications and Use Cases

• Wine Types: Suitable for still wines, sparkling wines (e.g., Champagne, Prosecco), and fermented beverages (e.g., cider, kombucha).

• Winery Size: Ideal for small to medium-sized wineries (due to semi-automatic operation) but scalable for larger productions with higher-capacity models.

• Quality Preservation: The line can be integrated with wine stabilization technologies (e.g., electromagnetic field treatment for microbial reduction8 and cold stabilization for tartrate precipitation) to enhance product shelf life.

💎 4. Advantages and Compliance

• Quality Assurance: Ensures consistent fill levels and secure corking, reducing waste and maintaining wine integrity.

• Flexibility: Adaptable to various bottle sizes and closure types (corks, crown caps) with quick changeover.

• Safety and Compliance: Meets Machinery Directive 2006/42/EC and other international standards. Includes safety guards and emergency stop systems3.

• Cost-Effectiveness: Low operational costs due to automated processes and minimal manual intervention.

📦 5. Optional Accessories and Customization

• Oxygen Evacuation Systems: Pre- or double pre-evacuation to further reduce oxygen exposure.

• Cold Stabilization Integration: For wineries requiring tartrate management.

• PET Bottle Adaptations: Neck handling devices for non-glass containers.

• CO₂ Injection: For sparkling wines to enhance carbonation retention before closure.
