Description
MD-10 High-Shear Dissolver for Cosmetic Products
MD-10 dissolver producing vitamin C serum nanoemulsion.
Rotor-stator head (5μm gap).
Touchscreen with emulsion particle size monitoring.
Core Technology
-
Nano-Scale Processing: Rotor-stator generator (5-20μm gap) delivers 25,000 s⁻¹ shear – creates stable nanoemulsions (≤200nm) for serum penetration.
-
Sanitary Design: Electropolished AISI 316L (Ra ≤0.4μm) with tri-clamp connections – zero dead legs (EHEDG Type EL-A).
-
Temperature Control: Jacketed vessel (-10°C to 150°C) prevents thermal degradation of actives.
-
Data Integrity: 21 CFR Part 11-compliant HMI with recipe management & audit trails.
Technical Specifications
| Parameter | Value |
|---|---|
| Batch Size | 50L-1000L |
| Shear Rate | Up to 25,000 s⁻¹ |
| Particle Size | 100mm-500nm (adjustable) |
| Viscosity Range | 1-500,000 cP |
| Cooling/Heating | -15°C to 160°C (±0.5°C) |
| Power | 7.5-22 kW (380V) |
| Surface Finish | Ra ≤0.4μm (internal) |
Cosmetic Applications
-
Skincare: Hyaluronic acid serums, vitamin C nanoemulsions (pH 3-9 stable).
-
Haircare: Silicone-oil blends for conditioners; eliminates «white caps».
-
Color Cosmetics: TiO₂/iron oxide dispersion for SPF foundations (Hegman grind ≤10μm).
-
Toiletries: Shear-thinning shower gels with pearlizing agents.
Performance Advantages
| Feature | Benefit |
|---|---|
| In-Line Homogenization | Recirculation loop achieves uniform particle size in 10-20 mins. |
| Gentle Hydration | Low-shear zone preserves fragile polymers (e.g., xanthan gum). |
| Scale-Up Accuracy | Identical shear profiles from R&D to production (CFD-verified). |
| Cleaning Efficiency | CIP cleans in <20 mins; SIP at 121°C/20 min for preservative-free products. |
Regional Adaptation
-
High-Humidity Sites: Condensation-proof control panels (85% RH operation).
-
Tropical Formulations: Cooling jackets prevent viscosity drop in heat.
-
Voltage Flexibility: 380V/415V/480V with GOST-R, CCC, INMETRO certifications.
Compliance & Certifications
-
Cosmetics: ISO 22716, EU Cosmetics Regulation 1223/2009.
-
Materials: FDA 21 CFR 700.13, REACH, Halal/Kosher options.
-
Safety: CE, ISO 13849 PLd.
-
Data: 21 CFR Part 11 (US), EU Annex 11 (GDPR).
Technical Support
-
Formulation Kits: Pre-set programs for serums/creams/shampoos.
-
Scale-Up Services: Free CFD shear mapping from lab to production.
-
Regional Validation: Documentation for ANVISA (Brazil), NPRA (ASEAN), MOH (GCC).
