M-20 Wall-Mounted Sanitary Agitator
M-20 installed on bioreactor in crowded lab.
Swivel bracket allowing 180° maintenance access.
Quick-release impeller change mechanism.
Engineering Innovations
-
Zero-Footprint Mounting: Bolt-on wall bracket frees floor space – ideal for crowded labs/pilot plants.
-
Modular Impeller System: Quick-change hydrofoils/anchors adapt to applications (cell culture → high-shear emulsification) in <10 mins.
-
Sanitary Design: Tri-clamp shaft connection with zero dead legs (ASME BPE-2022); Ra ≤0.4μm electropolish.
-
Sealing Integrity: Double mechanical seal (SiC/SiC) + steam barrier (<10⁻⁶ mbar·l/s leakage).
Technical Specifications
| Parameter | Value |
|---|---|
| Vessel Capacity | 50L-500L |
| Viscosity Range | 1-100,000 cP |
| Speed Range | 30-800 RPM (VFD) |
| Power | 0.37-2.2 kW (IP55/ATEX) |
| Projection | 450-900mm (adjustable) |
| Surface Finish | Ra ≤0.4μm (internal) |
Industry Applications
-
Pilot Scale Pharma: Mixing buffer solutions & vaccine adjuvants (GMP Annex 1 compliant).
-
Biotech Labs: Gentle cell culture agitation with low-shear impellers.
-
Cosmetic R&D: Emulsification of serums/creams in small batches.
-
Food Processing: Sauces and dairy blends (3-A compliant option).
Installation & Efficiency
| Feature | Benefit |
|---|---|
| Tool-Free Adjustment | Slide mechanism adjusts projection 450-900mm in seconds |
| Swivel Bracket | Rotate 180° for maintenance without disassembly |
| Energy Savings | Direct-drive motor reduces power loss 20% vs gearboxes |
| Modularity | Integrates with existing tanks via DIN 11851/Tri-clamp |
Regional Adaptation
-
High-Humidity Zones: Sealed electronics (IP55) withstand 90% RH.
-
Tight Facilities: 600×400mm footprint ideal for urban labs in Singapore/Mumbai.
-
Voltage Flexibility: 220V/380V models with GOST-R, CE, INMETRO certifications.
Compliance & Certifications
-
Pharma: FDA 21 CFR 211, EU GMP Annex 1.
-
Materials: USP Class VI, ASTM A270.
-
Safety: ISO 13849 PLc, PED 2014/68/EU.
-
Explosive Areas: ATEX II 2G Ex de IIC T4 (optional).
Technical Support
-
Lab Validation Kits: IQ/OQ templates for FDA/EMA compliance
-
Regional Spares: Seal/impeller kits stocked in Singapore, Dubai, Istanbul
-
CFD Shear Reports: Free fluid dynamics analysis for process optimization
📜 Schedule virtual airflow visualization test.
💡 Mention your: Target market (EU/US/Global South), Active ingredient, Required throughput.
🔬 Schedule virtual factory acceptance test with our engineers.
🏷️ Request Compliance Audit: Free gap analysis with throughput simulation.
