Description
M-10 Sanitary Top-Mounted Agitator for Process Vessels
M-10 agitator mounted on biopharma reactor.
Critical Design Features
-
Zero Contamination Design: Tri-clamp/DIN 11851 connections with zero dead legs (ASME BPE-2022) .
-
Material Integrity: AISI 316L (1.4404) with 16-32μ» electropolish (Ra ≤0.4μm) – exceeds EHEDG Type EL-A .
-
Advanced Sealing: Double mechanical seal (SiC/SiC) + steam barrier (<10⁻⁶ mbar·l/s leakage) .
-
Shear Flexibility: Interchangeable impellers (Rushton → Hydrofoil → Anchor) for 1-200,000 cP .
Technical Specifications
| Parameter | Value |
|---|---|
| Vessel Capacity | 50L-2000L |
| Viscosity Range | 1-200,000 cP |
| Speed Range | 20-1200 RPM (VFD) |
| Power | 0.37-7.5 kW (IP55/ATEX) |
| Pressure/Temperature | Full vacuum to 8 bar / -10°C to 155°C |
| Surface Finish | Ra ≤0.4μm (internal) |
Industry-Specific Configurations
-
Biopharma: CIP/SIP at 130°C/35 min; compliant with EU GMP Annex 1.
-
Vaccine Production: Low-shear hydrofoil impellers for sensitive cell cultures.
-
Food & Beverage: 3-A Symbol option; EHEDG-certified for dairy/sauces.
-
Fine Chemicals: Hastelloy® C-22 shafts for HCl/HNO₃ resistance.
Performance Highlights
| Feature | Benefit |
|---|---|
| Biofilm Prevention | Ra ≤0.4μm surface eliminates microbial adhesion |
| Energy Optimization | IoT-enabled VFD reduces power 30% (adaptive torque control) |
| Explosion Safety | ATEX II 2G Ex db IIC T4 motors for solvent use |
| Quick Maintenance | Seal replacement <15 min (tool-free cartridge) |
Regional Adaptation
-
Tropical Sites: 50°C-rated motors; humidity-resistant bearings (90% RH).
-
Coastal Facilities: Extra passivation layer for salt-air corrosion resistance.
-
Voltage Flexibility: 220V/380V/480V with GOST-R, CCC, INMETRO certs.
Compliance & Certifications
-
Pharma: FDA 21 CFR 211, EU GMP Annex 1.
-
Materials: USP Class VI, ASTM A270.
-
Safety: PED 2014/68/EU, ISO 13849 PLd.
-
Food: 3-A 63-07, EHEDG Type EL-A.
Technical Support
-
Validation Packages: IQ/OQ/PQ docs with 3D laser scans.
-
Regional Consumables: Seal kits stocked in Singapore, Dubai, Istanbul hubs.
-
CFD Optimization: Free fluid dynamics simulation for shear-sensitive processes.
📜 Schedule virtual airflow visualization test.
💡 Mention your: Target market (EU/US/Global South), Active ingredient, Required throughput.
🔬 Schedule virtual factory acceptance test with our engineers.
🏷️ Request Compliance Audit: Free gap analysis with throughput simulation.
Ready to Eliminate Production Bottlenecks?
Need Industrial Production Automation?
✅ GMP Compliance Guarantee
✅ 24/7 Multilingual Support
✅ 24-month performance guarantee
✅ Local technicians in 18 countries
Start small, get a free production layout designed for your growth trajectory. Scale smarter with engineering support!
📥Free line configuration for your products, throughput validation testing!
🎓Contact Specialists for Packaging Equipment:
📄 On-Demand Engineering: Product-specific configurations in 1-2 weeks.
🔧 Spare Parts Kits: Region-specific inventory for <24hr delivery.
🌡️ For a free product compatibility test using your materials.
Compliance Roadmap:
- CE, EAC, ISO 9001 certifications.
- GMP-ready: 316L SS contact parts, CIP/SIP capabilities.
- ATEX options for chemical solvents.
