LF-12 Gravity Filling System: High-Speed Precision for Bottling Lines
12-Nozzle Automatic Filler | 6,000 Bottles/Hour | ±0.5% Accuracy
Purpose & Applications
Ideal for:
✅ Household/Automotive Chemicals — Detergents, motor oils
✅ Food & Beverage — Syrups, cooking oils
✅ Cosmetics — Lotions, serums (including decorative cosmetics)
✅ Industrial Liquids — Solvents, lubricants
Key Advantage: Works standalone or integrated into automated lines — no conveyor reconfiguration needed.
Technology: Gravity-Fill Precision
✔ Timer-Based Dosing - No pistons/flow meters
✔ 12 Zero-Dead-Leg Nozzles - Eliminates drips
✔ Pneumatic Check Valves - ±0.5% fill accuracy
✔ Servo-Driven Nozzle Lift - Single motor controls all 12 nozzles
Technical Specifications
| Component | Specification |
|---|---|
| Product Tank | 250L 304/316L SS |
| Conveyor | 4.5m chain-driven |
| Control System | 10″ Touchscreen HMI (recipe storage) |
| Throughput | 6,000 bottles/hour (12-nozzle operation) |
| Fill Range | 50ml-5L containers |
| Safety | IP66 enclosure, emergency stop, air brakes |
Customization Options
-
Aggressive Chemicals Package
-
Full plastic construction (HDPE/PTFE)
-
Teflon-coated fluid path
-
Integrated fume hood
-
-
Explosion-Proof (ATEX/EX)
-
Certified for solvents/LPG environments
-
-
Pharma-Grade Upgrade
-
CIP/SIP capabilities
-
ISO Class 7 cleanroom compliance
-
Operation Workflow
-
Setup: Operator loads bottles → selects recipe on HMI
-
Filling Cycle:
-
Bottles indexed under nozzles
-
Air brakes position/center bottles
-
Nozzles descend (servo-controlled)
-
Valves open for preset time (10ms-60s)
-
-
Replenishment:
-
Level sensor triggers diaphragm pump
-
Maintains constant tank volume
-
Throughput Secret: Unified servo lifts all nozzles 2x faster than pneumatic systems.
Competitive Advantages
! vs. Piston Fillers
+ 40% lower maintenance
+ Handles particulates
! vs. Peristaltic
+ No tubing replacements
+ Higher viscosity tolerance
! vs. Competitor Gravity Fillers
+ 15% faster cycle times (patented valve design)
+ Integrated servo lift (single motor)
Why Choose LF-12?
Reduced changeover time from 45 to 5 minutes while achieving 99.8% fill accuracy with abrasive motor oils.
— Automotive Chemical Producer, Poland
