Description
Optimize Your Layout with a Compact and Efficient Conveyor System
The K-10 U-Shaped Turn Conveyor is the ideal solution for managing product flow in facilities with limited space or complex layouts. By enabling a 180-degree directional change, it allows you to create efficient, continuous loops and route boxes back toward their origin point without manual intervention. This is crucial for applications in order fulfillment, distribution centers, and post-packaging areas, where maximizing throughput in a confined area is a priority.
Key Features and Technical Advantages
-
Compact U-Turn Design: The unique V-shaped or U-shaped trajectory allows for a very compact layout, saving valuable production floor space.
-
Versatile Box Handling: Capable of transporting a wide range of cardboard boxes, plastic totes, and other lightweight unit loads commonly used in logistics.
-
Smooth and Quiet Operation: Engineered for minimal vibration and noise, contributing to a better working environment and reliable product handling.
-
Durable and Low-Maintenance: Built with high-quality materials, including a wear-resistant conveyor belt, to ensure long service life and minimize downtime.
Technical Specifications
| Parameter | Specification / Industry Example |
|---|---|
| Model | K-10 |
| Conveyor Type | U-Shaped (180°) Turn Belt Conveyor |
| Typical Load | Boxes, Cartons |
| Belt Width | 300 mm, 400 mm, 500 mm, 600 mm |
| Turn Angle | 180° |
| Speed Range | Adjustable, up to 60 m/min |
| Load Capacity | Up to 50 kg |
| Frame Material | Powder-coated carbon steel or Stainless Steel |
Industries and Applications
This U-shaped conveyor is essential for streamlining operations in multiple sectors:
-
Logistics & E-commerce: For order picking and consolidation in warehouses and distribution centers, creating efficient sorting loops.
-
Post-Packaging Lines: Transporting packaged goods from the end of a production line back toward palletizing stations or other processes.
-
Manufacturing & Assembly: Moving boxed components and finished products through compact assembly cells.
Engineered for Smart and Reliable Material Flow
The K-10 is more than a conveyor; it’s a smart layout solution. By incorporating a U-turn, it eliminates the need for multiple conveyors and complex transfer stations, leading to a simpler, more reliable system. Its robust design ensures consistent performance, helping to streamline operations in logistics and production facilities worldwide.
