Description
CZ-30 Class A Laminar Flow Cabinet Pharmaceutical Aseptic-Processing
CZ-30 Class A Laminar Flow Cabinet.
Performance Table:
| Parameter | Specification | Compliance Standard |
|---|---|---|
| Classification | EU GMP Grade A / ISO 5 | EU Annex 1 Revision 2023 |
| HEPA Filtration | H14 (EN 1822) | 99.995% @ 0.3μm |
| Airflow Velocity | 0.45 m/s ±0.05 m/s | ISO 14644-3:2019 |
| Work Surface | Electropolished SS316L | GMP Annex 1 Material Compliance |
| Noise Level | 62 dB(A) | EN ISO 3744:2010 |
| Monitoring | Real-time particle counter | 21 CFR Part 11 Option |
Critical Pharmaceutical Features
Annex 1 Compliance:
✅ Grade A Environment:
- <3,520 particles/m³ at 0.5μm size
- Continuous monitoring with data logging
✅ Material Integrity:
- Rounded corners (radius >2mm) for cleanability
- Non-shedding construction materials
✅ Contamination Control:
- UV-C decontamination cycles
- Positive pressure maintenance system
Applications:
• Aseptic Preparation: IV compounding, cytotoxic drugs
• Sterile Fill-Finish: Vial filling/stoppering operations
• Biotech**: Cell culture, vaccine research
• Microelectronics: Class 100 wafer processing
Competitive Differentiation
Smart Cabinet Technology:
🔬 Integrated Monitoring:
- Continuous particle counting (0.5μm/5.0μm)
- Differential pressure sensors with alarm triggers
- Temperature/RH monitoring (±0.5°C accuracy)
⚡ Energy Optimization:
- EC fan technology (40% less energy vs competitors)
- Night mode with reduced airflow (energy saver)
🌍 Global Adaptation Kits:
- Tropical package: Anti-mold coatings + dehumidifier
- Voltage stabilization: 90-264V auto-switching
- EMI shielding for sensitive electronics
Certification & Validation
Documentation Package:
📜 Included Reports:
- HEPA filter certification (IEST RP-CC001.6)
- Airflow visualization smoke studies (video)
- IQ/OQ protocols (installation/operational qualification)
🏷️ Global Certifications:
• CE • EAC • UKCA • FDA Subpart 211.65
🛠️ Validation Services:
- Onsite Annex 1 compliance testing
- Annual recertification programs
- 24/7 multilingual support
CZ-30 maintain Grade A conditions during monoclonal antibody preparation: 0.3μm particle count remains below 1,200 particles/m³ during operator interventions.
Technical Comparison Table
CZ-30 vs. Standard ISO 5 Cabinets:
| Feature | CZ-30 | Industry Average |
|---|---|---|
| Airflow Uniformity | ±5% variance | ±20-25% variance |
| Noise Level | 62 dB | 68-72 dB |
| Filter Access | Tool-less front access | Rear access requiring disassembly |
| Compliance Docs | Full Annex 1 package | Basic certification only |
| Energy Use | 0.55 kW/h | 0.85-1.2 kW/h |
📜 Schedule virtual airflow visualization test.
💡 Mention your: Target market (EU/US/Global South), Active ingredient, Required throughput.
🔬 Schedule virtual factory acceptance test with our engineers.
🏷️ Request Compliance Audit: Free gap analysis with throughput simulation.
Ready to Eliminate Production Bottlenecks?
Need Industrial Production Automation?
✅ GMP Compliance Guarantee
✅ 24/7 Multilingual Support
✅ 24-month performance guarantee
✅ Local technicians in 18 countries
Start small, get a free production layout designed for your growth trajectory. Scale smarter with engineering support!
Free line configuration for your products, throughput validation testing!
Contact Specialists for Packaging Equipment:
🌍 Regional Service Hubs: Dubai (MENA), Hanoi (SEA), Lagos (Africa).
📄 On-Demand Engineering: Product-specific configurations in 1-2 weeks.
📄 On-Demand Engineering: Product-specific configurations in 1-2 weeks.
⚙️ Rapid Customization: Customize equipment for unique products within 1-2 weeks.
🌐 Request Efficiency Audit: Free line analysis with 15% output improvement guarantee.
🛠️ On-Site Calibration: Available within 72hrs in key regions.
📊 Ramp-Up Assurance: On-site commissioning in <72hrs.
🔧 Spare Parts Kits: Region-specific inventory for <24hr delivery.
🔧 Spare Parts Kits: Region-specific inventory for <24hr delivery.
🌡️ For a free product compatibility test using your materials.
⚡Voltage customization available (110V-220V-380V-480V) — trusted by World industrial manufacturers in 16+ countries. Serving manufacturers in 12+ countries across Africa, SE Asia & MENA.
🛡️Support: EN/RU/AR/ES — On-site commissioning available globally.
📥Includes 24/7 remote monitoring and validation support (IQ/OQ/PQ).
✉️Multi-language HMIs, regional certifications included (International calls routed to English-speaking engineers).
Compliance Roadmap:
- CE, EAC, ISO 9001 certifications.
- GMP-ready: 316L SS contact parts, CIP/SIP capabilities.
- ATEX options for chemical solvents.
